SYSTEM CAPACITY

Up to 3 , 000 Managed Edgecore APs

Up to 30 , 000 Local Accounts

Up to 30 , 000 On-Demand Accounts

POWER

Input : 100-240 VAC , 50/60 Hz

Power cord included

Power Redundancy

Hot-swappable

LED Indicators

Power

Power Error

HDD

System Standby

User Security

Authentication : 802.1X , UAM ( browser-based ) , IP or MAC-based

Authentication Servers : Local , On-demand , Guest , RADIUS , LDAP , NT Domain , SIP , POP3

Customizable Captive Portal and Walled Garden

User Blacklisting

Account Generation

SMS Registration

Purchase via Paypal

Hotel PMS Integration

Selectable Billing Plans

Account Ticket Printer

Smart Login

Guest Wi-Fi Account

Social Media Login

Network Security

Remote , Site-to-Site VPN

Tunneling Protocols : IPSec , IKEv2

Intra-VLAN or Port-Based Network Isolation

Rogue AP Detection

Built-in Root CA Certificates

NETWORK SERVICES

High Availability : N+1 Redundancy with automatic synchronization

Internet Protocols Supported : IPv4 , IPv6

DHCP Server and Relay

Network Address Translation

Built-in HTTP Proxy Server

WAN Port Load Balancing

Dynamic Routing

Local DNS Records

Integrated Billing & Accounting System

Billing Quota Types : By duration; By Traffic Volume

Innkey PMS Integration

Oracle OPERA Hospitality Integration

IDS Next Integration

SYSTEM & NETWORK STATUS

System Dashboard

Graphical System Performance Reports

Traffic Volume Reports

System Process Monitor

Online Device Monitoring

Active Sessions List

Configurable SYSLOG Severity

SMTP ( E-mail ) Notifications

Multiple Concurrent E-mail Notification Receivers

PHYSICAL DIMENSIONS

19” ( 1U ) Rack Mount , Mounting bracket included

43.8 cm x 47.0 cm x 8.8 cm ( W x D x H )

Weight : 19.00 kg ( 41.90 lbs )

Interfaces

WAN : 2 x 10/100/1000Base-T Ethernet , Auto-MDIX , RJ-45

WAN : 2 x 10G SFP+

LAN : 2 x 10/100/1000Base-T Ethernet , Auto-MDIX , RJ-45

LAN : 2 x 10G SFP+

USB : 2 x USB3.0

Console : 1 x RJ-45

Management : 2 x RJ-45

Environmental Conditions

Operating Temperature : 0°C ( 32°F ) to 40°C ( 104°F )

Operating Humidity : 10% to 90% non-condensing

System Management

Browser-Based Configuration

System Backup and Restore

SNMP

Network Utilities

AP MANAGEMENT

Automatic AP Discovery and Provisioning

AP Firmware Batch Upgrade

Layer 2 and Layer 3 Tunneled AP Management

AP Load Balancing

Automatic AP Firmware Upgrade

Automatic Periodically AP Backup

Switch Management

Automatic Switch Discovery and Provisioning

Switch Configuration Backup & Restore

Switch Power Scheduling

USER MANAGEMENT

User Policy Assignment

Bandwidth Limitations

802.1p / DSCP Traffic Classification / Remarking

Stateful Firewall

Static Route Assignment

Concurrent Session Limit

IP Address Reassignment

Device Mobility

WISPr Smart Client

Cross Gateway Roaming

Fast Roaming Between APs

Mobile Device Optimized Captive Portal

Multiple Device Logins Per Account

QR Code Automatic Login

Device Plug-and-Play

On-Demand Smart Login without Re-Authentication

NETWORK ACTIVITY LOGS

System Log ( SYSLOG )

CAPWAP , Configuration Change , RADIUS Server , User Events Logs

User HTTP Web Log

Firewall Log

DHCP Server/Lease Log

PMS Interface Log

On-Demand Billing Report

AP Status E-mail Notification

AP Management Event Log

Logging to External FTP

Configurable Logs &Reporting; Intervals
