Radio
802.11 a/b/g/n/ac ; Wave 2
Concurrent Dual-band 2.4 / 5 GHz
Radio Chains : 4 x 4 : 4
RF Output Power*1 : 2.4 GHz : Up to 24 dBm*2; 5 GHz : Up to 24 dBm*2
( *1 : RF output power aggregates across MIMO chains and doesn’t contain antenna gain; *2 : Maximum power is limited by local regulatory requirements )
Frequency Band : 2.412 – 2.472 GHz , 5.180 – 5.825 GHz
Channelization : 20 MHz , 40 MHz , 80 MHz
Up to 16 ESSIDs per radio ( 32 total )
QUALITY OF SERVICE
Wireless QoS ( 802.11e / WMM )
DSCP ( 802.1p )
Airtime Fairness
Band Steering
Multicast to Unicast Conversion
Optimal Client Filtering
PHYSICAL DIMENSIONS
19.0 cm x 19.0 cm x 3.3 cm ( W x D x H )
Weight : 0.61 g ( 1.34 lbs )
Mounting : Wall/Ceiling mount ( Mounting kit included )
Interfaces
Uplink : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45 with 802.3at PoE
LAN : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45
Console : 1 x RJ-45 Port
USB : 1 x USB 2.0 Port
Antenna
Type : 5 x Built-in PIFA ( 4 x 2.4 GHz , 5 GHz , 1 x Bluetooth Low Energy )
Gain : 3 dBi ( 2.4 GHz ) , 5 dBi ( 5 GHz ) , 3 dBi ( BLE )
Environmental Conditions
Operating Temperature : 0°C ( 32°F ) to 45°C ( 113°F )
Operating Humidity : 5% to 95% non-condensing
Performance
Up to 600 Mbps ( 2.4 GHz )
Up to 1733 Mbps ( 5 GHz )
Up to 256 Concurrent Users ( 128 on 2.4 GHz , 128 on 5 GHz )
MOBILITY / ROAMING
Layer 2 / Layer 3 Fast Roaming
Hotspot 2.0
Security
Wireless Security : WEP , WPA / WPA2 Mixed , WPA2-Personal , WPA2-Enterprise ( 802.1X ) , TKIP and AES Encryption
VLAN Tagging ( 802.1Q )
Station Isolation
DHCP Snooping
Layer 2 Firewall
MANAGEMENT
Deployment : Standalone , Tunneled management by Edgecore EWS Gateway-Controller , IPv4 & IPv6 compatible , LLDP
Configuration : Web User Interface ( HTTP / HTTPS ) , SNMP v1 , v2c , v3
POWER
DC Input : 12V / 2.5A
PoE : 802.3at compliant ( PoE injector optional )
Power Consumption : 22.5W max.
LED Indicators
Power / 2.4G-WiFi / 5G-WiFi / ETH 1 ( PoE ) / ETH 2
Certifications
FCC ( United States )
CE ( Europe )
Bộ phát Wifi Concurrent Dual-Band 802.11ac Wave 2 Indoor Access Point Edgecore ECW5410-L
- Thương hiệu: EDGECORE
- Mã số sản phẩm: ECW5410-L
- Tình trạng kho: Đặt hàng qua Zalo hoặc Email
-
Xin liên hệ
