Radio
802.11 a/b/g/n/ac ; Wave 2
Concurrent Dual-band 2.4 & 5 GHz
Radio Chains : 2 x 2 : 2
Output Power : 2.4 GHz : Up to 22 dBm , 5 GHz : Up to 22 dBm ( Maximum power is limited by local regulatory requirements )
Frequency Band : 2.412 – 2.472 GHz , 5.180 – 5.825 GHz
Channelization : 20 MHz , 40 MHz , 80 MHz
Up to 8 ESSIDs
Performance
Up to 300 Mbps Data Rate ( 2.4 GHz )
Up to 867 Mbps Data Rate ( 5 GHz )
SYSTEM CAPACITY
Up to 2 , 000 Local Accounts
Up to 2 , 000 On-Demand Accounts
Security
Wireless Security : WEP , WPA / WPA2 Mixed , WPA2-Personal , WPA2-Enterprise ( 802.1X ) , TKIP and AES Encryption
VLAN Tagging ( 802.1Q )
Station Isolation
DHCP Snooping
Layer 2 Firewall
PHYSICAL DIMENSIONS
14.7 cm x 14.7 cm x 3.5 cm ( W x D x H )
Weight : 0.36 g ( 0.78 lbs )
Mounting : Wall/Ceiling mount ( Mounting kit included )
POWER
DC Input : 12V / 1.0A
PoE : 802.3af compliant ( PoE injector optional )
Power Consumption : 9.0W max.
Antenna
Type : 3 x Built-in PIFA ( 2 x 2.4 GHz , 5 GHz , 1 x Bluetooth Low Energy )
Gain : 3 dBi ( 2.4 GHz ) , 5 dBi ( 5 GHz ) , 3 dBi ( BLE )
Environmental Conditions
Operating Temperature : 0°C ( 32°F ) to 50°C ( 122°F )
Operating Humidity : 5% to 95% non-condensing
NETWORK SERVICES
Internet Protocols Supported : IPv4
Network Address Translation
Built-in HTTP Proxy Server
DHCP Server and Relay
Local DNS Records
Integrated Billing & Accounting System
Billing Quota Types : Duration , Volume , Time
USER MANAGEMENT
Simultaneous Support for Multiple Authentication Methods : Local , On-Demand , Guest , RADIUS
Social Media Login : Facebook , Google+ , Line , Open ID
User Policy Assignment
Bandwidth Limitations
Traffic Classification / Remarking
Stateful Firewall
Static Route Assignment
Concurrent Session Limit
Client Change Password Privilege
System Management
Browser-Based Configuration
Administrator Accounts
System Time
System Backup and Restore
SNMP
Network Utilities
Monitoring and Reporting
Online Status Monitoring of Users
IP-based Monitoring of Devices
User Traffic History Log
Configuration Change Log
Supports External SYSLOG Server for Diagnosis and Troubleshooting
Interfaces
Uplink : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45 with 802.3af PoE
LAN : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45
USB : 1 x USB 2.0 Port
LED Indicators
Power/2G-WiFi/5G-WiFi/LAN
Wireless Hotspot with Built-in User Access Control Edgecore ECH502
- Thương hiệu: EDGECORE
- Mã số sản phẩm: ECH502
- Tình trạng kho: Xin liên hệ
-
Xin liên hệ
