SYSTEM CAPACITY

Number of Managed VC : Up to 250

Number of Managed APs : Up to 10 , 000

Supported AP Model : ECW5211-L , ECW5410-L , ECWO5211-L , ECWO5213-L

POWER

Input : 100-240 VAC , 50/60 Hz

Power cord included

Power Redundancy

Hot-swappable

LED INDICATORS

Power

Power Error

HDD

System Standby

SIMPLIFIED DEPLOYMENT

Automatic devices discover and connect to EPC1000

Automatic provisioning without “click” routine via CAPWAP tunnel

Browser-based user interface configuration and monitoring

Built-in database for multiple application

CENTRALIZED CONFIGURATION

Role-based user policy assignment

Guest access functionality

802.1X authentication and UAM browser based authentication

Time-based QoS limitation

802.1Q VLAN tagging per SSID

Single update or bulk update of AP configuration profiles

Scheduled SSID visibility and firmware upgrade

Edgecore AP as DHCP server under NAT mode

GUEST ACCESS NETWORK

Simple access with existing social accounts inclusive of Facebook , Google+ , LINE , Weibo , VK and OpenID

Simple access with existing email addresses

One button login with terms of service agreement

Limited session time Wi-Fi service

Image or video advertisements delivering

Easy captive portal customization with WYSIWYG editor

Built-in 8 default themes for captive portals

NETWORK MANAGEMENT SYSTEM

Full visibility of platform resources

Virtual image information and version management

CPU and memory utilization monitoring

Disk health monitoring

License control for managed virtual controllers and APs

DASHBOARD

Graphical widgets and status with real-time information

360o views of managed network , systems , devices , and clients

Google Maps integration

Quick summary of the system alerts and notification

PHYSICAL DIMENSIONS

19” ( 1U ) Rack Mount , Mounting bracket included

43.8 cm x 47.0 cm x 8.8 cm ( W x D x H )

Weight : 19.00 kg ( 41.90 lbs )

INTERFACES

8 x 10/100/1000Base-T Ethernet , Auto-MDIX , RJ-45

4 x 10G SFP+

Console : 1 x RJ-45 , 1 x micro USB

USB ports : 2 x USB 3.0

Management : 2 x RJ-45

ENVIRONMENTAL CONDITIONS

Operating Temperature : 0°C ( 32°F ) to 40°C ( 104°F )

Operating Humidity : 10% to 90% non-condensing

STORAGE

SSD x 2

MONITORING

Real-time client list with traffic usage , uptime , and associated SSID

Intuitive AP list with basic information and wireless LAN status

Individual AP detailed radio monitoring in time dimension

Searching , sorting and customizable filters

Map based monitoring for checking the service device status

Built-in multi-site network management tools

REPORTING

Historical statistics of AP status and association summary

Selectable interval for reports generation

Quick glance of top clients and devices listed by their usage for analytics and reviews

Authenticated and unauthenticated clients information collection

Exportable reports in .csv or .pdf file for administrators

Periodically reports received via emails and FTP servers

TROUBLESHOOTING

Built-in troubleshooting utilities including ping and live packet captures

Radio detailed debugging information collection

Notification and Alarm logs for quick problem device identification and basic fault releasing

Email alert for specific AP status change , such as high CPU usage and high memory usage

System log and other specific function logs are centralized accessible
