Radio

802.11 a/b/g/n/ac

Concurrent Dual-band 2.4 / 5 GHz

Radio Chains : 2 x 2 : 2

Output Power : 2.4 GHz : Up to 10 dBm , 5 GHz : Up to 10 dBm ( Maximum power is limited by local regulatory requirements )

Frequency Band : 2.412 – 2.472 GHz , 5.180 – 5.825 GHz

Channelization : 20 MHz , 40 MHz , 80 MHz

Up to 8 ESSIDs per radio ( 16 total )

QUALITY OF SERVICE

Wireless QoS ( 802.11e / WMM )

DSCP ( 802.1p )

Multicast to Unicast Conversion

Optimal Client Filtering

PHYSICAL DIMENSIONS

US : 4.0 cm x 7.0 cm x 11.5 cm ( L x W x H )

EU : 4.0 cm x 8.5 cm x 8.5 cm ( L x W x H )

Weight : 125 g ( 0.275 lbs )

Mounting : In-Wall ( Mounting plate included )

Interfaces

Uplink : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45 with 802.3af PoE

LAN : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45

Bypass : 1 x RJ-11 ( front ) and 1x RJ-11 ( back )

Antenna

Type : 2 x Built-in ( 2 x 2.4 GHz , 2 x 5 GHz )

Gain : 2 dBi ( 2.4 GHz ) , 3.5 dBi ( 5 GHz )

Environmental Conditions

Operating Temperature : 0°C ( 32°F ) to 40°C ( 104°F )

Operating Humidity : 0% to 90% non-condensing

Performance

Up to 300 Mbps ( 2.4 GHz )

Up to 867 Mbps ( 5 GHz )

Up to 200 Concurrent Users ( 100 on 2.4 GHz , 100 on 5 GHz )

MOBILITY / ROAMING

802.1X Preauthentication

Layer 2 / Layer 3 Fast Roaming

Security

Wireless Security : WEP , WPA / WPA2 Mixed ( TKIP/AES Mixed ) , WPA2-Personal ( AES ) , WPA2-Enterprise ( AES )

VLAN Tagging ( 802.1Q )

Station Isolation

DHCP Snooping

Layer 2 Firewall

MANAGEMENT

Deployment : Standalone , Tunneled management by Edgecore EWS Gateway-Controller , IPv4 compatible , LLDP

Configuration : Web User Interface ( HTTP / HTTPS ) , SNMP v1 , v2c , v3

POWER

PoE : 802.3af compliant ( PoE injector optional )

Power Consumption : 8W max.

LED Indicators

Power

1 x LAN Status ( 100 Mbps )

1 x LAN Status ( 1 Gbps )
