Radio

802.11 a/b/g/n/ac; Wave 2

Concurrent Dual-band 2.4 & 5 GHz

Radio Chains : 2 x 2 : 2

RF Output Power*1 : 2.4 GHz : Up to 18 dBm*2; 5 GHz : Up to 18 dBm*2

( *1 : RF output power aggregates across MIMO chains and doesn’t contain antenna gain; *2 : Maximum power is limited by local regulatory requirements )

Frequency Band : 2.412 – 2.472 GHz , 5.180 – 5.825 GHz

Channelization : 20 MHz , 40 MHz , 80 MHz

Up to 16 ESSIDs per radio

QUALITY OF SERVICE

Bandwidth Management : Per User; WDS

Wireless QoS ( 802.11e / WMM )

DSCP ( 802.1p )

Airtime Fairness

Band Steering

Multicast to Unicast Conversion

Optimal Client Filtering

MANAGEMENT

Deployment : Standalone , Tunneled management by Edgecore EWS Gateway-Controller , IPv4 & IPv6 compatible , LLDP

Configuration : Web User Interface ( HTTP / HTTPS ) , SNMP v1 , v2c , v3

PHYSICAL DIMENSIONS

25.0 cm x 20.0 cm x 8.0 cm ( W x D x H )

Weight : 1.23 kg ( 2.71 lbs )

Mounting : Pole mount

POWER

PoE : 802.3at compliant or 48V / 0.5A passive PoE injector

Power Consumption : 20W max.

Environmental Conditions

Operating Temperature : -40°C ( -40°F ) to 65°C ( 149°F )

Operating Humidity : 10% to 95% non-condensing

IP68 Rating

Performance

Up to 300 Mbps ( 2.4 GHz )

Up to 867 Mbps ( 5 GHz )

Up to 256 Concurrent Users

MOBILITY / ROAMING

Layer 2 / Layer 3 Fast Roaming

Hotspot 2.0

Security

Wireless Security : WEP , WPA / WPA2 Mixed ( TKIP/AES Mixed ) , WPA2-Personal ( AES ) , WPA2-Enterprise ( AES )

VLAN Tagging ( 802.1Q )

Station Isolation

DHCP Snooping

Layer 2 Firewall

Operating Modes

AP Mode , WDS Mode

Interfaces

LAN : 1 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45 with 802.3at PoE

LAN : 2 x 10/100/1000Base-T Ethernet , Auto MDIX , RJ-45

Antenna

Horizontal : 38° ( 2.4 GHz ) , 30° ( 5 GHz )

Gain : 12 dBi ( 2.4 GHz ) , 12 dBi ( 5 GHz ) , 3 dBi ( BLE ) , 4 dBi ( GPS )

Certifications

FCC ( United States ) , CE ( Europe ) , NCC ( Taiwan )
