480W 48VDC DIN Rail Power Supply Unit D-Link DIS‑N480‑48
- Universal AC input/ Full range.
- Built-in active PFC function.
- Protections: Short circuit/ Overload/ Over voltage/ Over temperature.
- Cooling by free air convection.
- Can be installed on DIN rail TS-35/7.5 or 15.
- UL 508 (industrial control equipment approved.
- EN61000-6-2 (EN50082-2) industrial immunity level.
- 100% full load burn-in test.
Specifications
Model DIS‑N480‑48
OUTPUT
DC VOLTAGE 48V
RATED CURRENT 10A
CURRENT RANGE 0 ~ 10A
RATED POWER 480W
RIPPLE & NOISE (max.) 150mVp-p
VOLTAGE ADJ. RANGE 48 ~ 55V
VOLTAGE TOLERANCE ±1.0%
LINE REGULATION ±0.5%
LOAD REGULATION ±1.0%
SETUP, RISE TIME 1500ms, 100ms/230VAC 3000ms, 100ms/115VAC at full load
HOLD UP TIME (Typ.) 16ms/230VAC
16ms/115VAC at full load
INPUT
VOLTAGE RANGE 90 ~ 264VAC
127 ~ 370VDC
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF>0.98/115VAC, PF>0.94/230VAC at full load
EFFICIENCY (Typ.) 92.50%
AC CURRENT (Typ.) 4.8A/115VAC
2.4A/230VAC
INRUSH CURRENT (Typ.) 20A/115VAC 35A/230VAC
LEAKAGE CURRENT
PROTECTION
480W 48VDC DIN Rail Power Supply Unit D-Link DIS-N480-48
- Thương hiệu: D-LINK
- Mã số sản phẩm: DIS-N480-48
- Tình trạng kho: Xin liên hệ
-
Xin liên hệ
