Print Methods: Thermal transfer and direct thermal printing

Resolution: 203 dpi/8 dots per mm

300 dpi/12 dots per mm (optional)

Memory: 1 GB RAM memory

2 GB on-board linear Flash memory

Maximum Print Width: 6.6″/168 mm

Maximum Print Speed: 12 ips/305 mm per second

Media Sensors: Dual media sensors: transmissive and reflective

Maximum Continuous Print Length: 203 dpi: 150″/3810 mm

300 dpi: 100″/2540 mm

Media Width: 2.00″/51 mm to 7.0″/178 mm tear/cutter

2.00″/51 mm to 6.75″/171 mm peel/rewind

Maximum Media

Roll Size: 8.0″/203 mm O.D. on a 3″/76 mm I.D. core

Media Thickness: 0.0023″/0.058 mm to 0.010″/0.25 mm

Media Types: Continuous, die-cut, notch, black-mark

Ribbon Standard Length: 1476’/450 m

Ribbon Width: 2.00″/51 mm to 6.85″/174 mm

Ribbon Core: 1.0″/25.4 mm I.D.

Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code

2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec

Communications: USB 2.0, high-speed, RS-232 Serial, Gigabit Ethernet, Bluetooth 4.0

RFID:

Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols

Integrated RFID system is user-upgradeable in the field and available on both 4″ and 6″ models

Adaptive Encoding Technology automatically selects optimum encode settings

Supports industrystandard, multi-vendor, chip-based serialization

Supports block permalocking of user memory compatible with ATA Spec 2000

Allows users to track performance with RFID job-monitoring tools
