Đặc tính Giá trị

Print Methods: Thermal transfer and direct thermal printing

Resolution: 203 dpi/8 dots per mm

300 dpi/12 dots per mm (optional)

600 dpi/24 dots per mm (optional)

Memory: 256 MB SDRAM memory

512 MB on-board linear Flash memory

Maximum Print Width: 4.09 in./104 mm

Maximum Print Speed: 14 ips/356 mm per second

Media Sensors: Dual media sensors: transmissive and reflective

Maximum Continuous Print Length: 203 dpi: 157 in./3988 mm

300 dpi: 73 in./1854 mm

600 dpi: 39 in./991 mm

Media Width: 1.00 in./25.4 mm to 4.5 in./114 mm tear/cutter

1.00 in./25.4 mm to 4.25 in./108 mm peel/rewind

Maximum Media

Roll Size: 8.0 in./203 mm O.D. on a 3 in./76 mm I.D. core

Media Thickness: 0.0023 in./0.058 mm to 0.010 in./0.25 mm

On-metal option: up to 0.059 in./1.5 mm

Media Types: Continuous, die-cut, notch, black-mark

Ribbon Standard Length: 1476 ft./450 M

Ribbon Width: 2.00 in./51 mm to 4.33 in./110 mm

Ribbon Core: 1.0 in./25 mm I.D.

Linear Barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2- or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code

2D Barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec

Communications: USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 4.1, Dual USB Host

RFID:

Integrated RFID system is user-upgradable in the field

Optional field-upgradeable on-metal version available (ZT411 only)

Prints and encodes tags with a minimum pitch of 0.6 in./16 mm

Supports tags compatible with: UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols

Compliant with Global RFID radio to support multinational deployments

Automatically eliminate complex RFID placement guidelines with adaptive encoding technology

Variable inlay placement supports a range of inlay positions for maximum media flexibility

Track performance with RFID job-monitoring tools

Support for industry standard multi-vendor chip-based serialization (MCS)

Supports block permalocking of user memory compatible with ATA Spec 2000

Integrated ThingMagic® RFID reader/encoder
