Đặc tính Giá trị

Standards Supported: EPC Class 1 Gen 2; EPC Gen2 V2

RFID Engine: Zebra Proprietary Radio Technology

Fastest Read Rate: 1,300+ tags/sec

Nominal Read Range: ~22 ft./~6.7 m

Frequency Range and

RF System Output: US: 902–928 MHz; 0–30 dBm (EIRP)

EU: 865–868 MHz; 0–30 dBm (EIRP)

916.3, 917.5, and 918.7 MHz; 0–30 dBm (EIRP)

Japan: 916–921 MHz (w LBT), 0–30 dBm (EIRP)

Radio: IEEE 802.11 ax/ac/a/b/g/n 2X2, MU-MIMO, IPv4

Data Rate: 5 GHz PHY data rates up to 1.2 Gbps;

2.4 GHz PHY data rates up to 458 Mbps

Security and Encryption: TKIP, AES, EAP-TLS, EAP-PEAPv2, EAP-TTLS, EAP-FAST, PEAP, LEAP

SE4750MR Standard Range Imager

Sensor Resolution: 1280 x 960 pixels

Field of View: 31° horizontal, 23° vertical

Skew Tolerance: ±60°

Pitch Tolerance: ±60°

Roll Tolerance: 360°

Focal Distance: 14.2 in./36.1 cm from front of engine

Aiming LED: 655 nm laser

Illumination: 2X warm white LEDs

SE4850 Extended Range Imager

Sensor ResolutionSensor Resolution: 1280 x 800 pixels

Field of View: Far: 12° horizontal, 7.6° vertical

Near: 32° horizontal, 20° vertical

Skew Tolerance: ±60°

Pitch Tolerance: ±60°

Roll Tolerance: 360°

Focal Distance: Far: 15–350 in./38.1–889 cm from front of engine

Near: 11 in./27.8 cm from front of engine

Aiming Element: 655 nm laser

Illumination Element: Hyper red 660 nm LED

Minimum Print Contrast: 25%

Host Connection: Electronic 8-Pin Connection (eConnex™)

Bluetooth 5.3

USB Cable Cup

Host Computer: Zebra mobile computers and tablets

3rd-party smartphones and tablets

Windows-based PCs

Mobile Computer Adaptors: eConnex, Bluetooth, OtterBox uniVERSE

Case System

Bluetooth Profiles Supported: SPP Profile

HID Profile

Apple iAP2/MFi

Remote Management: Wi-Fi 6

Ethernet Cradles

Via Attached Host Device

Dimensions: 7.4 x 3.2 x 6.8 in./189 x 83.4 x 173 mm

Weight: RFD9030 with SE4750MR: 25 oz./714 grams

RFD9030 with SE4850: 26.5 oz./751 grams
