THÔNG SỐ KỸ THUẬT

Dimensions

Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D

18.5 cm H x 7.7 cm W x 13.2 cm D

Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D

18.5 cm H x 7.7 cm W x 14.3 cm D

Weight Corded: 10.72 oz./304 g

Cordless: 14.18 oz./402 g

Input Voltage Range

Host powered: 4.5 VDC min., 5.5 VDC max.

External power supply: 11.4 VDC min., 12.6 VDC max.

Operating Current

DS3608-DPA (corded): 360 mA (RMS typical)

Standby Current

DS3608-DPA (corded): 100 mA (RMS typical)

Color Gray and Black

Supported Host Interfaces

USB, RS232, Keyboard Wedge

Industrial Ethernet: EtherNet/IP, Profinet, Modbus

TCP & Std TCP/IP

Battery

PowerPrecision+ 3100 mAh Li-Ion rechargeable battery

User Indicators

Direct decode indicator; LEDs; beeper; vibration

Scans per Full Charge 100,000+

Image Capture Basic

Illumination

Direct: Two (2) warm white light LED;

Diffuse: Ring of red 634 nm LEDs

Aimer 655 nm laser

Imager Field of View Horizontal: 46°, Vertical: 30°

Image Sensor 1,280 x 960 pixels

Minimum Print Contrast

15% minimum reflective difference

Skew/Pitch/Roll Skew: ± 60°

Pitch: ± 60°

Roll: ± 360°
