Đặc tính Giá trị

Swipe Speed (Hands-Free): Up to 240 in./610 cm per second for 13 mil UPC in optimized mode

Light Source: Aiming Pattern: Circular 528nm green LED

Illumination: (2) warm white LEDs

Imager Field of View: 48° H x 30.6° V Nominal

Image Sensor: 1280 x 800 pixels

Minimum Print Contrast: 16% minimum reflective difference

Skew Tolerance: ± 60°

Pitch Tolerance: ± 60°

Roll Tolerance: 0° – 360°

RFID Standard Supported: EPC Class 1 Gen2; EPC Gen2 V2; ISO-18000-63

RFID Engine: Zebra Proprietary Radio Technology

Nominal Read Range: ~18 in. / ~45.7 cm

RFID Power Output: 3 dBm to 22 dBm

RFID Frequency Range: US: 902 – 928 MHz

EU: 865 – 868 MHz

Japan: 916 – 923 MHz

Graphics Format Support: Images can be exported as Bitmap, JPEG or TIFF

Image Quality (A4 Document): 116 PPI on an 8.3 x 11.7 in./21.0 x 29.7 cm document @ 8.0 in./ 20.3 cm

1D: Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

2D: PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes

OCR: OCR-A, OCR-B, MICR, US Currency

Dimensions: 8.0 in. H x 3.9 in. W x 5.75 in. D

20.3 cm H x 9.9 cm W x 14.6 cm D

Weight: 14.8 oz./420.0 g
