Manufacturer Honeywell

Category CCTV>IP Dome cameras

Model code HC60W44R2L

Series 60 Series

Chip Inch Size 1/2.8 inch

Colour Type Colour / Monochrome

Resolution TVL 4MP

HD Yes

Megapixel Yes

Sensitivity lux 0 ~ 0.04

Indoor/Outdoor Outdoor

Digital (DSP) Yes

Electrical Specifications Voltage: 12 V DC, 24 V AC, PoE

Power Consumption: 12.95 W

Focal length 2.7 ~ 13.5 mm

Compression H.265 HEVC / H.264 / MJPEG, Smart Codec

Back Light Compensation Yes

Auto Gain Control Yes

White Balance Yes

Electronic Shutter range 1 / 30 ~ 1 / 32000

S/ N (Signal/ Noise) Ratio dB 60

Signal Mode NTSC, PAL

Built-in IR LED Yes

Network Properties Interface: 10 Base-T / 100 Base-TX Ethernet (RJ-45)

Network Protocols: IPv4, IPv6, TCP / IP, HTTP, HTTPS, UPnP, RTSP / RTP / RTCP, IGMP / Multicast,SMTP, DHCP, NTP, DNS, DDNS, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS

Image Frame Rate: 25 ~ 30 fps

Physical Specifications Dimensions mm: 159 x 159 x 118.3

Weight g: 1,113

Environmental Specifications Operating Temp oC: -30 ~ +60 C (-22 ~ +140 F)

Operating Humidity %: 0 ~ 90

Protection: IP66, IP67, IK10

System Requirments Operating System: Microsoft Windows 10

Web Browser: Chrome 79.0 / Internet Explorer 11

Additional info

1/2.8" 4MP progressive scan imager

2.7~13.5 mm, F1.4~F2.8, MFZ lens

Angle of view 100~30° (H) – 53~17° (V)

Best Main Stream: 2560x1440 (1 ~ 25/30fps), 1920x1080 (1 ~ 50/60fps)

Best Sub Stream: 2560x1440 (1 ~ 25/30fps), 1920x1080 (1 ~ 50/60fps)

Best Third Stream: 1280x720 (1 ~ 50/60fps)

Wide Dynamic Range (WDR) up to 120 dB

Low light performance (0.04 lux in color mode)
