Thông số kỹ thuật:

OPERATIONAL

VIDEO STANDARD NTSC/PAL

SCANNING SYSTEM Progressive

IMAGE SENSOR 1/2.8” 2 Megapixel progressive CMOS

NUMBER OF PIXELS (H × V) 1920(H) x1080(V)

MINIMUM ILLUMINATION 0.05lux/F1.4(color,30IRE)

0Lux/F1.4(IR on)

S/N RATIO More than 45dB

ELECTRONIC SHUTTER SPEED 1/3~1/100000s

IR DISTANCE Up to 60m(197ft), depending on scene reflectance

IR LIGHT CONTROL Manual/SmartIR/OFF

IR LIGHT NUMBER 4

DAY/NIGHT Auto(ICR) / Color / B&W

BACKLIGHT COMPENSATION BLC / HLC / WDR

WHITE BALANCE Auto/Natural/Street Lamp/Outdoor/Manual/Customized Region

GAIN CONTROL 0~100

WIDE DYNAMIC RANGE 120dB

NOISE REDUCTION 3D DNR

PRIVACY MASKING Off / On (4 Areas, Rectangle)

MOTION DETECTION Off / On (4 Zones, Rectangle)

REGION OF INTEREST Off / On (4 Zones)

LENS 2.7mm~13.5mm, Motorized, F1.4

ANGLE OF VIEW H:108°~30°, V:60°~18°

VIDEO

VIDEO COMPRESSION H.265/H.264H/Smart Codec/MJPEG (Sub Stream)

RESOLUTION

1080P(1920×1080)/1.3M(1280×960)/

720P(1280×720)/D1(704×480/576)/

VGA(640×480)/ CIF(352×240/288)

FRAME RATE Main Stream: 1080P(1~25/30fps)

Sub Stream: D1(1~25/30fps)”

BIT RATE CONTROL CBR/VBR

BIT RATE H.265: 12K ~ 6400Kbps

H.264: 32K ~ 10240Kbps

NETWORK

ETHERNET RJ-45 (10/100Base-T)

SUPPORTED WEB BROWSERS Internet Explorer (11.0+)

SUPPORTED OS Windows® 7 32-bit/64-bit;

Windows® 10 32-bit/64-bit

PROTOCOLS* HTTP; HTTPs; TCP; ARP; RTSP; RTP; RTCP; UDP; SMTP; DHCP; DNS; PPPoE; IPv4/v6; QoS; UPnP; NTP; Bonjour; IEEE 802.1x; Multicast; ICMP; IGMP; TLS

INTEROPERABILITY ONVIF Profile S/G/Q

MAXIMUM USERS ACCESS 20 Users

SECURITY

User account and password protection HTTPS, IP Filter, Digest authentication, User access log, TLS1.2 only, AES-128/256, SSH/Telnet closed, sFTP by default, PCIDSS compliance

EVENT No SD card, SD card error, Capacity warning, Network disconnection, IP conflict, Illegal access

MICRO SD Up to 128 GB microSDHC card, Class 10 (not included)

ELECTRICAL

POWER SUPPLY DC12V PoE (802.3af)(Class 0)

POWER CONSUMPTION <11.4W (-ZS)

MECHANICAL

DIMENSIONS 72mm×80mm×212.8mm (2.8″ x 3.1″x 8.4″)

PRODUCT WEIGHT 0.64kg (1.41lb)

PACKAGE WEIGHT 0.82kg (1.80lb)

MATERIAL Die-cast aluminum housing with powder coat

CONSTRUCTION COLOR RAL 9003 (White)

ENVIRONMENTAL

OPERATING TEMPERATURE -30° C ~ +60° C (-22° F ~ +140° F)

RELATIVE HUMIDITY Less than 95%, non-condensing

INGRESS PROTECTION IP66

REGULATORY

EMISSIONS FCC Part 15B, EN 55032

IMMUNITY EN 50130-4

SAFETY UL 60950-1, EN 62368-1

ROHS EN 50581
