Thông số kỹ thuật:

OPERATIONAL

Video Standard NTSC/PAL

Scanning System Progressive

Image Sensor 1/3” CMOS

Number Of Pixels (H x V) 2560×1440

Minimum Illumination (Color/BW) 0.005 lux @F1.6, AGC ON; 0 lux with IR

S/N Ratio ≥50db

Electronic Shutter Speed 1/2s ~ 1/100,000s

IR Distance 20 ~ 30 m

IR Light Control Smart IR (Auto/Manual)/OFF

Day/Night ICR

Backlight Compensation WDR, HLC, BLC

White Balance Auto/Indoor/Outdoor/Manual

Gain Control Auto/Manual

Wide Dynamic Range 120dB

Noise Reduction 3D DNR

Lens 2.8mm@ F1.6

Angle Of View H:94°, V:50°

Privacy Masking Off / On (4 Areas)

Local Storage Micro SD (up to 256 GB)

VIDEO

Video Compression

Main stream: H.265 / H.264

Sub stream: H.265 / H.264 / MJPEG

Third stream: H.265 / H.264 / MJPEG

Resolution

4MP (2560 × 1440), 3MP (2304 × 1296),

1080P (1920 × 1080), 720P (1280 × 720), D1,

480× 240, CIF

Number of Video Streams 3

Frame Rate Main Stream

60Hz: 4MP/3MP/1080P/720P(1~30fps);

50Hz: 4MP/3MP/1080P/720P(1~25fps)

Frame Rate Second Stream

60Hz: 720P/D1/CIF (1~30fps);

50Hz: 720P/D1/CIF (1~25fps)

Frame Rate Third Stream

60Hz: D1/480× 240/CIF (1~30fps);

50Hz: D1/480× 240/CIF(1~25fps)

Bit Rate 64 Kbps ~ 8 Mbps

Ingress Protection IP67

Impact Resistance IK10

REGULATORY

Emissions EN 55032, FCC PART 15

Immunity EN 55035

Safety IEC 60950-1, IS 13252(Part 1)

RoHS IEC 62321

AUDIO

Audio Compression G.711A/G.711U

Audio Stream 1-way

Audio Interface 1CH audio input; 1CH built-in MIC

NETWORK

Ethernet 10 Base-T/100 Base-TX Ethernet (RJ-45)

Supported Web Browsers Chrome/Edge

Supported OS Microsoft Windows 10

Protocols*

IPv4, IPv6, TCP / IP, UDP, DHCP, NTP, RTSP, RTP,

RTCP, PPPoE, DNS, DDNS, SMTP, FTP, 802.1x,

SNMP, UPnP, HTTP, HTTPs, QoS, IGMP / Multicast,

ICMP, ARP, TLS

Interoperability ONVIF Profile G/S/T

Maximum Users Access 3 Users

Security

User account and password protection, HTTPS, IP

Filter, Digest authentication, TLS1.2 only, AES128

/ 256, SSH / Telnet closed

Languages Supported

English, Italian, Portuguese, Russian,

Spanish(Mexico), Dutch, French, German, Polish,

Japanese, Chinese, Korean

EVENTS / ANALYTICS

Built-in Video Analytics

Motion Detection, Tampering, Intrusion, Object,

Video Exception (scene change, video blur and

video cast detection), line crossing detection and

region intrusion detection

Region Of Interest 8

ELECTRICAL

Power Supply 12VDC, PoE (IEEE 802.3af) (Class 3)

Power Consumption (Max) MAX 5W

MECHANICAL

Dimensions (D x D x H) Ø 94.6 mm × 82.8 mm (Ø 3.72″ x 3.25″)

Product Weight 0.46 kg (1.01lb)

Package Weight 0.56 kg (1.23lb)

Body Material Metal housing

ENVIRONMENTAL

Operating Temperature -30 °C ~ 60 °C (-22°F~140°F)

Relative Humidity Less than 90% (non-condensing)

SYSTEM COMPATIBILITY

20 Series NVR Integration with 20 Series NVR
