Thông số kỹ thuật:

OPERATIONAL

Video Standard PAL/NTSC

Scanning System Progressive

Image Sensor 1/2.8” Progressive Scan CMOS

Number Of Pixels(H x V) 1920(H)×1080(V)

Minimum Illumination (Color/BW) 0.1 Lux @ (F1.2,AGC ON) /0 Lux @ (IR LED ON)

S/N Ratio 55 db

Electronic Shutter Speed Auto/Manual, 1/5 ~ 1/20,000s

IR Distance Up to 30 m (98.4 ft)

IR Light Control Auto/Manual

Day/Night Auto(ICR)/Day / Night

Backlight Compensation DWDR, BLC, HLC

White Balance Auto/Manual

Gain Control 0-100%

Wide Dynamic Range DWDR

Noise Reduction 2D/3D DNR

Lens Fixed Focal, 4mm, F2.0

Angle Of View (H x V x D) H: 87.8°, V: 44.4°

Privacy Masking Off / On (4 Areas, Rectangle)

Defog Supported

Local Storage Built-in Micro SD slot, up to 256GB (SD card level Class 10 or above)

VIDEO

Video Compression H.265 HEVC/ H.264

Number of Video Streams 2 Streams

Frame Rate

Main Stream: 1920×1080, 1280×720 @ 25/30fps

Sub Stream: 704×576, 640×360, 480×360, 352×288 @ 25/30fps

Bit Rate

Main Stream: 128kbps ~ 4096kbps, default 2048kbps

Sub Stream: 16kbps ~ 1536kbps, default 1024kbps

NETWORK

Ethernet 1 Ethernet (10/100 Base-T) RJ-45 Connector

Supported Web Browsers IE11, Chrome, Firefox, Microsoft Edge

Supported OS Microsoft Windows 10

Protocols* IPv4, RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, DDNS, UPNP, ICMP, IGMP, NTP, SMTP, SNMP

Interoperability ONVIF Profile S

Maximum Users Access 4 Users

Languages Supported

English, Chinese (Simplified), French, Korean, Polish, Italian, Spanish, German, Hungarian, Russian, Vietnamese, Thai, Danish, Czech, Slovakia, Indonesian, Portuguese, Dutch, Hebrew, Arabic, Turkish

EVENTS / ANALYTICS

Video Analytics Motion Detection, Intrusion, Line Crossing, Tampering

Event Linkage Event notification using Email and MicroSD card

ELECTRICAL

Power Supply DC12V, 1A; or POE (IEEE 802.3af)

Power Consumption (Max) Max 5.5W

MECHANICAL

Dimensions Ø182 mm × 66.2 mm × 66.2 mm (7.16″ × 2.61″ × 2.61″)

Product Weight 0.35 kg (0.77 lb)

Package Weight 0.46 kg (1.01 lb)

Body Material Die-cast aluminum housing

Color Honeywell White (RAL9003), Pantone Black

ENVIRONMENTAL

Operating Temperature -25°C ~ 55°C (-13°F ~ 131°F )

Relative Humidity Less than 90% RH

Ingress Protection IP66

REGULATORY

Emissions FCC PART 15, CE (EN 55032)
