Thông số kỹ thuật:

Video Standard NTSC / PAL

Scanning System Progressive

Image Sensor 1/2.8” CMOS

Sensor size (H x V) 5.568mm x 3.132mm

Number Of Pixels (H × V) 2MP (1920 x 1080 mm)

Min. illumination (Color/B/W)

Color: 0.07 lux @F1.6 1/30sec

BW: 0 lux @F1.6 (IR on)

S/N Ratio > 50 dB

Electronic Shutter Speed 1/100000 ~ 1/1

Day/Night Auto (ICR)/Color/BW

IR Distance Distance up to 200m

IR Light Control Smart IR (Auto/Manual)/OFF

IR Light Number 18

Backlight Compensation WDR, BLC, HLC

White Balance Auto / Fixed Current / Manual

Gain Control 0 ~ 100 %

Wide Dynamic Range 120 dB

Noise Reduction 3D DNR

Lens 40x Optical Zoom , Auto Focus , 4.25mm ~ 170mm, DC-IRIS, F1.6 ~ F4.95

Electronic Image Stabilization Support

Angle Of View H: 65.66° ~ 1.88° V:39.4° ~ 1.09°

G-Sensor Support G-Sensor XYZ OSD Display (Default – Off)

Privacy Masking Off / On (24 Areas)

Defog Support

Encryption Chipset FIPS 140-2 Certified Chipset Built-in

Local Storage Micro SD / SDHC / SDXC card slot (up to 256 GB)

Micro USB Support Wifi Dongle for configuration

Alarm Inputs / Outputs 2 In / 1 Out

PTZ

Pan Speed 0.05° ~ 440°/sec

Pan Range 360° endless

Tilt Speed 0.05° ~ 350° / sec.

Tilt Range 220° (-110° ~ + 110°)

Preset Locations 256 preset locations, 128 presets per tour

Preset Accuracy 0.1°

Auto Pan Scan Support

Auto Tracking Support

Auto Resume After Power Failure Support

VIDEO

Video Compression H.265 HEVC / H.264 / MJPEG, Smart Codec

Resolution (16:9) 1920 x 1080 / 1600 x 904 / 1360 x 768 / 1280 x 720 / 640 x 360

Number of Video Streams 3

Frame Rate Main Stream

MAX 30fps Mode: 1920 x 1080 (1-25 / 30 fps)

MAX 60fps Non-True WDR mode: 1920 x 1080 (1-50 / 60 fps)

Frame Rate Second Stream

MAX 30fps Mode:1920 x 1080 / 1280 x 720 / 640 x 360 (1-25 / 30 fps)

MAX 60fps Non-True WDR mode: 1920 x 1080 (1-50 / 60 fps)

Frame Rate Third Stream

MAX 30fps Mode: 1920 x 1080 / 1280 x 720 / 640 x 360 (1-25 / 30 fps)

MAX 60fps Non-True WDR mode: 1920 x 1080 (1-50 / 60 fps)

Bit Rate (Control) 20 K ~ 80 Mbps

AUDIO

Audio Compression G.711 / G.726

Audio Stream 2-Way, Full duplex

Audio Interface Line In / Out

NETWORK

Ethernet 10 Base-T / 100 Base-TX Ethernet (RJ-45)

Supported Web Browsers Chrome 79.0 Internet Explorer 11

Supported OS Microsoft Windows 10

Protocols*

IPv4, IPv6, TCP / IP, HTTP, HTTPS, UPnP, RTSP / RTP / RTCP, IGMP / Multicast, CIFS / SMB, SMTP, DHCP, NTP, DNS, DDNS, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS

Interoperability ONVIF Profile G / S

Maximum Users Access 10 Users

Security

User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, Stream encryption, AES128 / 256, SSH / Telnet closed, PCIDSS compliance, FIPS 140-2 Certified Chipset Built-in

Languages Supported English, French, German, Italian, Japanese, Portuguese, Russian, Spanish, Traditional Chinese

EVENTS / ANALYTICS

Video Analytics Intrusion, Loiter, Line crossing, Unattended object, Missing object, Face detection

Event type Video motion detection, Periodically, Alarm input, System boot, Recording notification, Camera tampering detection

Event linkage Event notification using digital output, HTTP, Email and MicroSD card

Region Of Interest 5

ELECTRICAL

Power Supply AC 24 V~, 3 A, 50-60 Hz ; or UPoE 42.5-57 V , MAX 51 W

Power Consumption MAX 51 W

MECHANICAL

Dimensions (Ø x H) Ø243.92 mm x 455.28 mm (Ø9.6 x17.9”)

Product Weight 6.95kg (15.3lb)

Package Weight 8.75kg (19.3lb)

Material Aluminum and Plastic

Construction Color Honeywell White, Pantone Black

ENVIRONMENTAL

Operating Temperature

Starting Temperature: -40 °C ~ 60 °C (-40 °F ~ 140 °F)

Working Temperature: -40 °C ~ 60 °C (-40 °F ~ 140 °F) (IR OFF)

Relative Humidity Less than 90 %, non-condensing

Ingress Protection IP66/NEMA 4X

PTZ casing IK10

Heater Supported

REGULATORY

Emissions FCC PART 15, CE (EN 55032)

Immunity CE (EN 50130-4)

Safety

UL LISTED TO UL / CSA 62368-1, CE (EN 62368-1),

UL / CSA 60950-22, CE (EN 60950-22)

RoHS CE (EN 50581), UAE (Cabinet Decree No.10 of 2017)
