Thông số kỹ thuật:

OPERATIONAL

RAM 1 GB

Flash 512 MB

Video Standard NTSC/PAL

Scanning System Progressive

Image Sensor 1/2.8” CMOS

Pixel Size 2.0 μm x 2.0 μm

Sensor Size (H x V) 5.216 x 3.928 mm

Number of Pixels (H x V) 2 MP (1920 x 1080)

Minimum Illumination (Color/BW) 0.002Lux@F1.6

S/N Ratio > 55 dB

Electronic Shutter Speed 1/3 ~ 1/100,000

IR Distance Up to 60m

IR Light Control Smart IR (Auto/Manual)/OFF

IR Light Number 10

Removable IR-Cut Filter Yes

Day/Night Auto/Day/Night/Timing

Backlight Compensation WDR, HLC, BLC

White Balance Auto/Tungsten/Fluorescent/Daylight/Shadow

Gain Control 0 ~ 100 %

Wide Dynamic Range 140 dB

Noise Reduction 3D DNR

Lens 2.7 ~ 13.5 mm, MFZ, DC-Iris, F1.4 ~ F2.8

Digital Image Stabilization Yes

Angle of View (H x V) H:94° ~ 30° V: 52° ~ 17°

Privacy Masking Off/On (4 Areas)

Defog Yes

Encryption Chipset Hardware embedded

Local Storage Micro SD/SDHC/SDXC card slot (1TB)

Alarm Inputs/Outputs 2 in/1 out

Reset Supported

*For detailed information about frame rate and bit rate, please refer to the User Guide.

** Some development may be required in specific user cases to support some of these protocols in the field

as they mature over time.

VIDEO

Video Compression H.265/H.264/MJPEG, Smart codec

Resolution (16/9) 1920 x 1080/1280 x 720

Resolution (4/3) 640 x 480/320 x 240

Number of Video Streams 3

Frame Rate*

Main Stream: 1920 x 1080 50/60fps, 1280 x 720 25/30fps

Second Stream: 1920 x 1080/704 x 576 (PAL)/704 x 480

(NTSC)/640 x 480/352 x 288 (PAL)/352 x 240(NTSC) 25/30fps

Third Stream: 640 x 480/352 x 288 (PAL)/352 x 240 (NTSC)/320 x 240 25/30fps

Bit Rate* 100K ~ 12Mbps

Analog Output Support CVBS (Reserved)

AUDIO

Audio Compression G.711a/ G.711Mu

Audio Stream Full duplex

Audio Interface Line in/out, Built-in Mic

NETWORK

Ethernet 10 Base-T/100 Base-TX Ethernet (RJ-45)

Supported Web Browsers Microsoft Edge, Chrome

Supported OS Microsoft Windows 10, Windows 11

Protocols**

IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS

Interoperability ONVIF Profile G/S/T/M

Maximum Users Access 10 Users

Security

Software: Firmware encrypted&Signed, SD card encryption, User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, Stream encryption, AES128/256, SSH/Telnet closed, PCIDSS compliance & attestation

Hardware: Secure boot, Secure authentication chipset built-in

Languages Supported

Arabic, Chinese (Traditional), Czech, Dutch, English, French, German, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Spanish, Turkish

EVENTS / ANALYTICS

Video Analytics

Standard: Motion detection, Scene change

AI Based: Smart motion, Intrusion, Multi loitering, People counter, Face detection, Line crossing detection, Unattended object detection, Missing object detection

Event Type Analytics alarm, Security alarm, Disk alarm, Recording alarm, Audio detection

Event Linkage Email, Push notification, SD card recording, Digital output

Region of Interest 8

Event Event notification using digital output SMTP, FTP, MicroSD card

ELECTRICAL

Power Supply AC24V, DC12V, PoE (IEEE 802.3af)(Class 0)

Power Consumption (Max) 9.36 W

MECHANICAL

Dimensions 303.5 x 104.9 x 114.6 mm (11.95” x 4.13” x 4.51”)

Product Weight 1.36 kg (2.99 lb)

Package Weight 1.60 kg (3.53 lb)

Body Material Metal (die casting aluminum with powder coating)

Color Hon dark gray + White (RAL9003)

ENVIRONMENTAL

Operating Temperature

Starting temperature: -40 °C ~ 60 °C (-40 °F ~ 140 °F)

Working temperature: -40 °C ~ 60 °C (-40 °F ~ 140 °F) (IR off)

Relative Humidity Less than 90 %, Non-condensing

Ingress Protection IP66, IP67

Impact Resistance IK10

Gore Vent Supported

REGULATORY

Emissions FCC PART 15, CE (EN 55032), ICES-003, Complies with RCM and UKCA

Immunity CE (EN 50130-4, EN 55035), Complies with RCM and UKCA

Safety UL listed to UL/CSA 62368-1, CE (EN 62368-1), Complies with RCM and UKCA

RoHS CE (EN 63000), UAE (Cabinet Decree No.10 of 2017)
