480W 24VDC DIN Rail Power Supply Unit D-Link DIS‑N480‑24

- Universal AC input/ Full range

- Built-in active PFC function

- Protections: Short circuit/ Overload/ Over voltage/ Over temperature

- Cooling by free air convection

- Can be installed on DIN rail TS-35/7.5 or 15

- UL 508 (industrial control equipment approved

- EN61000-6-2 (EN50082-2) industrial immunity level

- 100% full load burn-in test

Specifications

Model DIS‑N480‑24

OUTPUT

DC VOLTAGE 24V

RATED CURRENT 20A

CURRENT RANGE 0 ~ 20A

RATED POWER 480W

RIPPLE & NOISE (max.) 150mVp-p

VOLTAGE ADJ. RANGE 24 ~ 28V

VOLTAGE TOLERANCE ±1.0%

LINE REGULATION ±0.5%

LOAD REGULATION ±1.0%

SETUP, RISE TIME 1500ms, 100ms/230VAC 3000ms, 100ms/115VAC at full load

HOLD UP TIME (Typ.) 16ms/230VAC

16ms/115VAC at full load

INPUT

VOLTAGE RANGE 90 ~ 264VAC

127 ~ 370VDC

FREQUENCY RANGE 47 ~ 63Hz

POWER FACTOR (Typ.) PF>0.98/115VAC, PF>0.94/230VAC at full load

EFFICIENCY (Typ.) 92.5%

AC CURRENT (Typ.) 4.8A/115VAC

2.4A/230VAC

INRUSH CURRENT (Typ.) 20A/115VAC 35A/230VAC

LEAKAGE CURRENT

PROTECTION

OVERLOAD 105 ~ 130% rated output power

Protection type: Constant current limiting, unit will shut down after 3 sec., re-power on to recover

OVER VOLTAGE 29 ~ 33V

Protection type: Shut down o/p voltage, re-power on to recover

OVER TEMPERATURE Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT

WORKING TEMP. -20 ~ +70 (Refer to 'Derating Curve')

WORKING HUMIDITY 20 ~ 95% RH non-condensing

STORAGE TEMP., HUMIDITY -40 ~ +85 , 10 ~ 95% RH

TEMP. COEFFICIENT ±℃ ℃ 0.03%/ (0 ~ 50 )
