Đặc tính Giá trị

CPU: Snapdragon Wear™ 4100 Platform/SDW429w, quad-core, 2.0 GHZ

Operating System: Android 11 AOSP

Memory: 1 GB RAM/8 GB Flash

Display: 2 in. AMOLED 460 x 460 color display; optically bonded to touch panel

Imager Window: Corning® Gorilla® Glass

Touch Panel: Capacitive touch panel; fingertip and glove support; Corning® Gorilla® Glass

Power: Standard (Wrist): 3.08 Watt Hours; 800 mAh

High Capacity (Converged): 5 Watt Hours; 1300 mAh

PowerPrecision; Hot Swap (2 minutes, memory persistent)

Network Connections: USB 2.0 High Speed (host and client), WLAN and Bluetooth

Notifications: Audible tone; charge LED; OS notification LED;

multi-color Application LEDs; haptic feedback

Voice and Audio: Speaker (90dBA); internal mic; PTT ready; Bluetooth headset support

Buttons: Wrist: 4 buttons (programmable)

Converged: trigger; 2 buttons (programmable)

Interfaces: Docking contacts; Via interface cables: USB-C (USB 2.0) host/client and charging

Optical Resolution: 1280 x 800 pixels

Roll: 360°

Pitch: ±60°

Skew: ±60°

Aiming Element: 655 nm Laser

Illumination Element: 1 Hyper Red 660 nm LED or 1 Warm-White LED

Field of View: Horizontal: 48°, Vertical: 30°

Ambient Light Immunity (from total darkness): Maximum 107,639 lux (direct sunlight)

Supported 1D Symbologies: Code 39, Code 128, Code 93, Codebar/NW7, Code 11, MSI, UPC/EAN, I 2 of 5, Korean 3 of 5, GSI DataBar, Base 32 (Italian Pharma)

Supported 2D Symbologies: PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes

Supported OCR Symbologies: OCR-A, OCR-B

Scan Triggering: Manual ambidextrous trigger or automatic via Proximity Sensor technology

Light Sensor: Automatically adjusts display backlight brightness

Motion Sensor: 6-axis accelerometer with MEMS Gyro

Scanning: Converged: SE4770 1D/2D standard range omni-directional imager

Wrist: 13 MP camera with flash, or no data capture option

Camera: 13 MP with Flash (Wrist only)

NFC: Tap to Pair, ISO 14443 Type A and B, Felica and ISO 15693 cards, and Card Emulation via Host (HCE) support

Scan Triggering: Manual or automatic via proximity sensor technology

Radio: IEEE 802.11 a/b/g/n/ac/d/h/i/r; Wi-Fi™ certified; IPv4, IPv6, 1×1 SISO

Data Rates: 2.4 GHz: 802.11b/g/n/ac — 20 MHz, 40 MHz — up to 200 Mbps

5 GHz: 802.11a/g/n/ac — 20 MHz, 40 MHz, 80 MHz — up to 433 Mbps

Operating Channels: Channel 1-13 (2412-2472 MHz); Channel 36-165 (5180-5825 MHz)

Channel Bandwidth: 20, 40, 80 MHz

Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency

Security and Encryption: WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); — EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, EAP-PWD

Certifications: WFA (802.11n, 80211ac, WPA2-Personal, WPA3-Personal, WPA2-Enterprise, PMF)

Fast Roam: PMKID caching; 802.11r (Over-The-Air); OKC

Bluetooth: Bluetooth 4.2; Bluetooth Low Energy (BLE) support; Class 1
