• Thiết bị chuyển mạch Công Nghiệp 4×10GBase-X SFP+ slot++8 ×1000Base Combo port+16×1000Base-X SFP slot single power, AC220V Wintop YT-CM3728-4WF8GC16GF

16-Port Gigabit SFP + 4-Port 10GBase-X SFP+ + 8-Port Combo Layer 3 Managed Switch WINTOP YT-CM3728-4WF8GC16GF

- Cung cấp 4 cổng sợi quang 10 Gigabit, 8 cổng Combo SFP/RJ45 Gigabit và 16 cổng đồng Gigabit.

- Thiết kế không quạt, đạt tiêu chuẩn bảo vệ IP30, vỏ kim loại chịu va đập.

- Điện áp hoạt động: AC220V.

- Đáp ứng các yêu cầu về tương thích điện từ (EMC), bao gồm chống sét, phóng tĩnh điện, xung sét và xung điện áp.

- Hỗ trợ nhiều phương pháp quản lý như Web, CLI, Telnet, SSH và giao diện Web song ngữ (Tiếng Trung/Anh).

- Hỗ trợ cấu hình ERPS, STP, RSTP và MSTP.

- Hỗ trợ định tuyến tĩnh.

- Hỗ trợ SNMP V1/V2c/V3.

Technical Parameters

Support standards IEEE 802.3i (10Base-T), IEEE 802.3u(100Base-T)

IEEE 802.3ab(1000Base-T), IEEE 802.3z(1000Base-SX/LX)

IEEE 802.3ae(10GBase-X)

IEEE 802.3ad (port aggregation), IEEE802.3x (flow control)

IEEE 802.1p (priority), IEEE 802.1Q (VLAN)

IEEE 802.1D (STP), IEEE 802.1w (RSTP)

IEEE 802.1s(MSTP), IEEE 802.1p (QoS)

Protocol IGMP Snooping, GMRP, GVRP, DHCP, SNMPv1/v2c/v3, TFTP, NTP, SNTP, Ping, Traceroute, RMON, HTTPS, SSH, Telnet, Syslog, ERPS, MLD, LLDP, LACP, ACL

MIB: MIB-II, BRIDGE MIB, Ethernet MIB, IF MIB, RMON MIB Group 1, 2, 3, 9

Switching features Qos queue: 8

Packet forwarding rate: 252Mpps

VLAN-ID: 1-4094

Backplane bandwidth: 598Gbps

MAC address table: 8K

Message cache size: 42 Mbit

Interface Debug port: RS-232 (Interface type: RJ45 slot)

10G optical port: 10G/1000Mbps (Interface type: SFP slot)

Gigabit optical port: 1000Mbps (Interface type: SFP slot)

Gigabit electrical port: 10/100/1000 Mbps adaptive, Full/Half duplex mode, supports MDI/MDI-X

LED indicator: PWR, Link/ACT, SPD, RUN

Power requirements Input voltage: AC 220V

Physical properties Shell: Iron shell IP30 protection

Size: 440 x 280 x 44 mm

Weight: 4380g

Installation method: rack

Environmental restrictions Operating temperature: - 40 ~ 45°C (-40 ~ 113°F)

Storage temperature: -40 ~ 85°C (-40 ~ 185°F)

Ambient relative humidity: 5 ~ 95% (non-condensing)

Standards and Certifications Electromagnetic susceptibility (EMS): IEC61000-4-2 (ESD) Level 4, IEC 61000-4-4 (EFT) Level 4, IEC 61000-4-5 (Surge) Level 4 (4kv port lightning protection, 4kv power supply lightning protection)

Vibration resistance: IEC 60068-2-6

Impact resistance: IEC 60068-2-27

Free fall: IEC 60068-2-32

Certification: CE, FCC, Rohs, Ministry of Industry and Information Technology network access license, Ministry of Public Security inspection report

MTBF (mean time between failures) Time: 500000 hours

- Bảo hành: 24 tháng.

Không có đánh giá nào cho sản phẩm này.

Viết đánh giá

Lưu ý: HTML is not translated!
    Xấu           Tốt

Thiết bị chuyển mạch Công Nghiệp 4×10GBase-X SFP+ slot++8 ×1000Base Combo port+16×1000Base-X SFP slot single power, AC220V Wintop YT-CM3728-4WF8GC16GF

  • Thương hiệu: WINTOP
  • Mã số sản phẩm: YT-CM3728-4WF8GC16GF
  • Tình trạng kho: Liên hệ
Đơn giá chưa VAT. Phải cộng thuế VAT khi mua hàng
  • 15.664.000 đ

    15.664.000 đ
