CPU Multimedia SoC (System-on-Chip)

Flash 256MB

RAM 512MB

Camera Features

Image Sensor 1/2.8″ progressive scan CMOS

Max. Resolution 1920×1080 (2MP)

Lens Type Fixed-focal

Focal Length MD9561-H(2.8mm): f = 2.8 mm

MD9561-H(3.6mm): f = 3.6 mm

Aperture MD9561-H(2.8mm): F1.8

MD9561-H(3.6mm): F2.0

Auto-iris Fixed-iris

Field of View MD9561-H(2.8mm):

110° (Horizontal)

63° (Vertical)

129° (Diagonal)

MD9561-H(3.6mm):

90° (Horizontal)

49° (Vertical)

109° (Diagonal)

Shutter Time 1/5 sec. to 1/32,000 sec.

WDR Technology WDR Pro

Day/Night Yes

Removable IR-cut Filter Yes

IR Illuminators Built-in IR illuminators, effective up to 30 meters with Smart IR, IR LED*2

Minimum Illumination MD9561-H(2.8mm):

0.07 Lux @ F1.8 (Color)

0.01 Lux @ F1.8 (B/W)

0 Lux with IR illumination on

MD9561-H(3.6mm):

0.08 Lux @ F2.0 (Color)

0.01 Lux @ F2.0 (B/W)

0 Lux with IR illumination on

Pan Range ±30°

Tilt Range 90°

Rotation Range ±180°

Pan/Tilt/Zoom Functionalities ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)

On-board Storage Slot type: MicroSD/SDHC/SDXC card slot

Seamless Recording

Video

Video Compression H.265, H.264, MJPEG

Maximum Frame Rate 60 fps @ 1920×1080

Maximum Streams 4 simultaneous streams

S/N Ratio MD9561-H(2.8mm): 60 dB

MD9561-H(3.6mm:): 55 dB

Dynamic Range 120 dB

Video Streaming Adjustable resolution, quality and bit rate control, Smart Stream III

Image Settings Adjustable image size, quality and bit rate; Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, 3DNR, video rotation, defog

Audio

Audio Capability One-way Audio

Audio Compression G.711, G.726

Audio Interface Built-in microphone

External line input

Effective Range 5 meters
