System Information

CPU Multimedia SoC (System-on-Chip)

Flash 16GB

RAM 4GB

Camera Features

Image Sensor 1/1.8″ Progressive CMOS

Max. Resolution 3840×2160 (4K/8MP)

Lens Type Motorized, Vari-focal, Remote Focus

Focal Length f = 3.9 ~ 10 mm

Aperture F1.5 ~ F2.7

Auto-iris P-iris

Field of View 119° ~ 45° (Horizontal)

63° ~ 25° (Vertical)

142° ~ 52° (Diagonal)

Shutter Time 1/10 sec. to 1/33,333 sec.

Day/Night Yes

Removable IR-cut Filter Yes

IR Illuminators Built-in IR Illuminators up to 50 meters

Minimum Illumination 0.28 Lux @ F1.5 (Color)

<0.005 Lux @ F1.5 (B/W)

0 Lux with IR illumination on

Pan Range 353°

Tilt Range 80°

Rotation Range 180°

Video

Compression H.265, H.264

Maximum Frame Rate 30 fps @ 3840×2160

Maximum Streams 4 simultaneous streams

S/N Ratio 53.5 dB

Dynamic Range 69.6 dB

Video Streaming Adjustable resolution, quality and bit rate control

Network

Protocols DHCP, DNS, HTTP, HTTPS, IPv4, IPv6, RTSP/RTP/RTCP, NTP, TCP/IP

Interface 10 Base-T/100 Base-TX/1000 Base-T Ethernet (RJ45)

ONVIF Supported, specification available at www.onvif.org

Solution Integration

VCA Supported by S&ST APPs

General

Connectors RJ-45 cable connector for 10/100/1000Mbps Network/PoE connection *1

DC 12V power input*1

AC 24V power input*1

Digital input*1

Digital output*1

LED Indicator System power and status indicator

Power Input IEEE 802.3at Class3 PoE

DC 12V

AC 24V

(Power Redundancy)

Power Consumption Max. 25 W

Dimensions Ø 155 x 138 mm

Weight 1,343 g

Casing IP66, IP67, IK10, NEMA 4X

Safety Certifications CE, FCC Class A, VCCI, C-tick, UL, BIS

Operating Temperature Starting Temperature:

-40°C ~ 60°C (-40°F ~ 140°F)

Working Temperature:

-50°C ~ 60°C (-58°F ~ 140°F) (IR off)

-50°C ~ 50°C (-58°F ~ 122°F) (IR on)

Humidity 95%

Warranty 36 Months

System Requirements

Web Browser Windows: Mozilla Firefox, Chrome, Microsoft Edge

Mac OS: Safari

Linux: Chrome

Other Players VLC: 1.1.11 or above

Included Accessories

Others Waterproof connectors, desiccant bags, alignment sticker
