Model

AW-GEL-065A-060

Product Description 4xGE PoE + 2xGE UTP Lite Managed Switch

Port Configuration

10M/100M/1G PoE Port 4

10M/100M/1G RJ45 Port 2

IEEE 802.3x V

IEEE 802.3u V

IEEE 802.3ab V

Total Ports 6

HW Performance

Switching Bandwidth 12 Gbps

Buffer Memory1 1 Mb

MAC Address 8K

Jumbo Frames 9216 Bytes

Lite Managed Features

Spanning Tree Protocol

IEEE 802.1d (STP) V

IEEE 802.1w (RSTP) V

Link Aggregation Control Protocol V

VLAN

802.1Q Tag-based VLAN 4096 VLAN IDs

Port-based VLAN V

QoS

CoS port-based V

CoS 802.1p-based V

CoS DSCP-based V

Loop Protection V

Flow Control V

Strom Control V

Port-Based Mirroring V

Port Isolation V

Bandwidth Control V

Satic MAC V

PoE Management

PoE On/Off Control V

PoE Auto Checking V

Non-Stop PoE V

Extend PoE Mode (250M) V

PoE Function

IEEE 802.3 PoE Standard Compliant 802.3 af/at

Number of PoE Output Port 4

PoE Output Power 30W

Totoal PoE Power Budget 60W

PoE Pin Assignment 1/2(+), 3/6(-)

PoE Surge Protection 4KV Per PoE port

Environmental Specifications

Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)

Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)

Operating Humidity 10 ~ 90% RH

Mechanical Specifications

Dimensions 200 (W) x 118 (D) x 44 (H) mm

Weight 0.66 kg

Power Source

AC Input 100V ~ 240V

Frequency 50 ~ 60 Hz

Power Consumption 65W

Certifications

Certifications CE, FCC, LVD, VCCI

Warranty

Warranty 24 months

Accessories

Included Accessories Power Cord, QIG, Rack Mount Kit
