Thông số kỹ thuật :

HARDWARE SPECIFICATIONS

Copper Ports 24 10/100/1000BASE-T RJ45 copper ports

PoE Injector Port 24 ports with 802.3af/802.3at PoE+ injector function

SFP Slots 2 x 100/1000BASE-X SFP interface

Flash Memory 16Mbytes

Reset Button < 10 sec: System reboot

> 10 sec: Factory default

ESD Protection Contact ±6KV , Air ±8KV

Surge Protection Differential mode ±2KV , Common mode ±4KV

Dimensions (W x D x H) 440 x 207 x 44mm

Weight 2500g

Power Consumption 9.4 watts/32BTU (System)

297 watts/1012 BTU (System + PoE)

Power Requirements AC 100~240V, 50/60Hz

Fan 2

LED System:

PWR (Green)

PoE Usage 80% (Green)

Ports:

LNK/ACT (Green)

PoE-in-Use (Amber)

SWITCHING SPECIFICATIONS

Switch Architecture Store-and-forward

Switch Fabric 52Gbps/non-blocking

Switch Throughput 38.68Mpps

Address Table 8K MAC address table with auto-learning, auto-aging

Shared Data Buffer 4.1MB

Jumbo Frame 10KBytes

Flow Control Back pressure for half duplex

IEEE 802.3x pause frame for full duplex

POWER OVER ETHERNET SPECIFICATIONS

PoE Standard IEEE 802.3at PoE+ PSE

PoE Power Supply Type End-span

PoE Power Output 32W (max.)

Power Pin Assignment 1/2(+), 3/6(-)

PoE Power Budget 260 watts (max.)

LAYER 2 FUNCTIONS

Port Configuration EEE Green energy savings disable/enable

Port disable/enable/reboot

Flow control disable/enable

Bandwidth control on each port

Port loopback protection

Port Status Display each port’s speed duplex mode,

Display link status

Display flow control status

Display auto negotiation status

Display Green energy saving status

Port Mirroring In / Out / All

Many-to-1 monitor

VLAN 802.1Q tagged VLAN, up to 4K VLAN groups

Bandwidth Control TX/RX/Both

Link Aggregation static trunk

Supports 8 groups with 8 ports per trunk group

QoS 8 priority queues on all switch ports

Supports strict priority and Weighted Round Robin (WRR) CoS policies

Traffic classification:

IEEE 802.1p CoS/ToS

IPv4 DSCP

Port-based WRR

Multicast IPv4 IGMP v1/v2 snooping

Up to 256

SECURITY FUNCTIONS

Security Port isolation

DHCP Snooping

SWITCH MANAGEMENT FUNCTIONS

System Configuration Telnet, Web browser

Management Authentication for IPv4 Telnet user name and password

Telnet

Cable Diagnostics

IP address or domain name Ping Test

PLANET Smart Discovery Utility

PLANET NMS system

PLANET NMSViewerPro

STANDARD CONFORMANCE

Regulatory Compliance FCC Part 15 Class A, CE

Standards Compliance IEEE 802.3 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3z Gigabit 1000BASE-SX/LX

IEEE 802.3ab Gigabit 1000BASE-T

IEEE 802.3x flow control and back pressure

IEEE 802.1p Class of Service

IEEE 802.1Q VLAN tagging

IEEE 802.3af Power over Ethernet

IEEE 802.3at Power over Ethernet PLUS

RFC 783 TFTP

RFC 791 IP

RFC 792 ICMP

RFC 2068 HTTP

RFC 1112 IGMP v1

RFC 2236 IGMP v2

ENVIRONMENT

Operating Temperature: 0 ~ 50 degrees C

Relative Humidity: 5 ~ 90% (non-condensing)

Storage Temperature: -10 ~ 70 degrees C

Relative Humidity: 5 ~ 90% (non-condensing)
