CertificationsEN 60601-1-1 and EN 60601-1-2 ( for deployment in medical environments ) Wi-Fi Alliance certified ( WFA ) 802.11ax with ( Wi-Fi 6 ) , WPA2 , WPA3

Input VoltagePower over Ethernet ( POE ) : 802.3af ( class 3 ) DC power ( 12V ) Note : Power sources are sold separately

Wi-Fi AntennaIntegrated down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz ( of the effective , combined pattern for both antennas in each band ) .

ConnectivityIEEE 802.11ax

External I/O Ports ( 1 ) uplink Gigabit Ethernet port , with POE-in support ( 802.3af )

MountingThe access point ships with a white mount clip that can attach to both wall and ceiling. You can also purchase a mount ( R6P90A ) that matches the aesthetic design and looks of the APs , to blend seamlessly into your environment.

Power Consumption DescriptionMax power consumption ( worst-case ) : 10.1W ( PoE ) , 8.8W ( DC )

Radio CoverageDual Radio for simultaneous dual-band operation 5 GHz 802.11ax 2x2 MIMO for up to 1.2 Gbps wireless data rate , with Multi User MIMO support ( Wi-Fi 6 ) 2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate ( Wi-Fi 6 )

Warranty Standard StatementAruba Instant On 2 Year warranty with 24X7 phone support for first 90 days and chat support for the entire warranty period. Community support as long as you own the products.

Product Differentiator ( long ) Aruba Instant On AP22 Indoor Access Points offer a reliable , affordable , and business-grade 802.11ax Wi-Fi experience for high performance , high-density small business environments like hotels , restaurants , and professional offices. Supporting Wi-Fi 6 standard , these access points have a peak data rate of 1.2 Gbps and scale up to 25 access points , without additional cost and complexity. For use in those countries and regions where no specific regulatory domain is required.

Weight ( imperial ) 1.1 lb

Weight ( metric ) 500 g

Product Dimensions ( imperial ) 1.5 x 6.3 x 6.3 in

Product Dimensions ( metric ) 37x 160 x 160 mm
