Thông số kỹ thuật:

SYSTEM

MAIN PROCESSOR ARM Processor

OPERATING SYSTEM EMBEDDED LINUX

ONVIF COMPLIANCE ONVIF PROFILE S

VIDEO

IP CAMERA INPUTS 8 / 16 Channels

SECURITY

IP CAMERA INPUTS NDAA Section 889 Compliant

ENCRYPTION Trusted Platform Module (TPM)

MAXPRO CLOUD (WEB/MOBILE) HTTPS Login, User based privilege

WEB CLIENT SYSTEM

BROWSERS Chrome

OPERATING SYSTEM Windows, MAC

MOBILE IOS, Android

SECURITY HTTPS Login, User based privilege

LIVE VIEW

SECONDARY STREAM H.264 Live Video

STREAMING RTMP, Image Streaming

RESOLUTIONS 720p, D1, CIFStreaming MSE

FRAME RATE Up to 30FPS

NUMBER OF LIVE SESSIONS Unlimited

SALVO VIEW 1/4/6/8 (Configurable)

SITES IN SALVOS Multi-site

ON-SITE RECORDING

PRIMARY STREAM H.264 Recorded Video

RESOLUTIONS Up to 8MP

FRAME RATE Up to 30FPS

RECORDING MODE VMS, Input Trigger, Rule Trigger, User Trigger, Schedule recording (24*7)

RECORDING DURATION Pre-event + Event duration + Post-event

PRE-EVENT 5 secs Max

POST-EVENT 30, 40, 50, 60 Secs

ON-SITE PLAYBACK SESSION 8 CH – 8 / 16 CH – 10

OFF-SITE RECORDING

PRIMARY STREAM H.264 video push

STREAMING HLS Streaming

RESOLUTIONS Up to 4K

FRAME RATE Up to 30FPS

RECORDING MODE VMS, Input Trigger, Rule Trigger, User Trigger

EVENT RECORDING DURATION Pre-event + Event duration + Post-event

PRE-EVENT 5 secs Max

POST-EVENT 30, 40, 50, 60 Secs

CLOUD STORAGE (DAYS) 7, 30, 60, 90, 180, 365, FIFO

MAX NO OF STREAMING CLIENTS Unlimited

STORAGE

INTERNAL HDD Internal x 4 (3.5″)

HDD MAX CAPACITY 10 TB

CLOUD (OFF-SITE) EVENT CLIPS (7, 30, 60, 90, 180,365 DAYS)

VIDEO SEARCH, PLAYBACK, CLIP REPORT

VIDEO SEARCH, PLAYBACK, CLIP REPORT VMD, Input Trigger, Rule Trigger, User Trigger

EVENT SEARCH Playback from Alarms

PLAYBACK FUNCTION Play, Pause, Jump Forward or Reverse

CLIP EXPORT Onsite, Offsite

SITE CONFIGURATION

MULTIPLE DEVICE (Video/Access , under same site)

PEOPLE (Users with different access level)

CAMERA CONFIGURATION

RESOLUTION, FPS (Primary and Secondary Streams)

RECORDING SCHEDULE (Continuous and Event)

VMD CONFIGURATION Enable VMD and Region from

ENVR Local View

OFFLINE CONFIGURATION DOWNLOAD Not yet supported

REGULATORY

EMISSIONS FCC Part 15G, CE EN55022

IMMUNITY CE EN50130-4

SAFETY EU: EN60950-1 North America UL

Listed to UL/CSA 60950-1
