Thông số kỹ thuật:

OPERATIONAL

VIDEO STANDARD NTSC/PAL

SCANNING SYSTEM Progressive

IMAGE SENSOR 1/2.8″ 2 Megapixel progressive scan CMOS

NUMBER OF PIXELS (H × V) 1920(H) x1080(V)

MINIMUM ILLUMINATION 0.05lux/F1.4(color,30IRE) 0Lux/F1.4(IR on)

S/N RATIO More than 45dB

ELECTRONIC SHUTTER SPEED 1/3~1/100000s

IR DISTANCE Up to 50m (164ft), depending on scene reflectance

IR LIGHT CONTROL Manual/Smart IR/OFF

IR LIGHT NUMBER 2

DAY/NIGHT Auto(ICR) / Color / B/W

BACKLIGHT COMPENSATION BLC / HLC / WDR

WHITE BALANCE Auto/Natural/Street Lamp/Outdoor/Manual/ Customized Region

GAIN CONTROL 0~100

WIDE DYNAMIC RANGE 120dB

NOISE REDUCTION 3D DNR

PRIVACY MASKING Off / On (4 Areas, Rectangle)

MOTION DETECTION Off / On (4 Zones, Rectangle)

REGION OF INTEREST Off / On (4 Zones)

FACE DETECTION NA

LENS 2.7mm~13.5mm, Motorized, F1.4

ANGLE OF VIEW H:108°~30°, V:60°~18°

VIDEO

VIDEO COMPRESSION H.265/H.264H/Smart Codec/MJPEG (Sub Stream)

RESOLUTION 1080P(1920×1080)/1.3M(1280×960)/ 720P(1280×720)/D1(704×480/576)/ VGA(640×480)/CIF(352×240/288)

FRAME RATE Main Stream: 1080P (1~25/30fps) Sub Stream: D1(1~25/30fps)

BIT RATE CONTROL CBR/VBR

BIT RATE H.265: 12K ~ 6400Kbps H.264: 32K ~ 10240Kbps

NETWORK

ETHERNET RJ-45 (10/100Base-T)

SUPPORTED WEB BROWSERS Internet Explorer (11.0+)

SUPPORTED OS Windows® 7 32-bit/64-bit; Windows® 10 32-bit/64-bit

PROTOCOLS* HTTP; HTTPs; TCP; ARP; RTSP; RTP; RTCP; UDP; SMTP; DHCP; DNS; PPPoE; IPv4/v6; QoS; UPnP; NTP;

INTEROPERABILITY ONVIF Profile S/G/Q

MAXIMUM USERS ACCESS 20 Users

SECURITY User account and password protection HTTPS, IP Filter, Digest authentication, User access log, TLS1.2 only, AES-128/256, SSH/Telnet closed, sFTP by default, PCIDSS compliance

EVENT No SD card, SD card error, Capacity warning, Network disconnection, IP conflict, Illegal access

MICRO SD Up to 128 GB microSDHC card, Class 10 (notincluded)

ELECTRICAL

POWER SUPPLY DC12V, PoE (IEEE802.3af) (Class 0)

POWER CONSUMPTION <9.5W

MECHANICAL

DIMENSIONS Ø122mm x 102mm(4.8’’ x4.0’’)

PRODUCT WEIGHT 0.60Kg(1.32lb)

PACKAGE WEIGHT 0.75kg (1.65lb)

CONSTRUCTION Die-cast aluminum housing with powder coat

CONSTRUCTION COLOR RAL 9003 (White)

ENVIRONMENTAL

OPERATING TEMPERATURE -30° C ~ +60° C (-22° F ~ +140° F)

RELATIVE HUMIDITY Less than 95%, non-condensing

INGRESS PROTECTION IP66

REGULATORY

EMISSIONS FCC Part 15B, EN55032

IMMUNITY EN 50130-4

SAFETY UL 60950-1, EN 62368-1

ROHS EN 50581
