Thông số kỹ thuật:

OPERATIONAL

RAM 1 GB

Flash 512 MB

Video Standard NTSC/PAL

Scanning System Progressive

Image Sensor 1/1.8” CMOS

Sensor size (H x V) 7.860 x 4.460 mm

Number of Pixels (H x V) 4MP (2592 × 1520)

Minimum Illumination (Color/BW)

Color: 0.005 lux @ F1.6

BW: 0 lux @ F1.6 (IR on)

S/N Ratio ≥55 dB

Electronic Shutter Speed 1/1 to 1/30,000 sec

IR Distance up to 450 M

IR Light Control Smart IR (Auto/Manual)/OFF

IR Light Number 8

Day/Night Auto/Day/Night/Timing

Backlight Compensation WDR, HLC, BLC

White Balance Auto/Tungsten/Fluorescent/Daylight/Shadow

Gain Control 0~100 %

Wide Dynamic Range 140 dB

Noise Reduction 3D DNR

Lens 5.3 mm ~ 212 mm, F1.5 ~ F4.8, DC Iris

Digital Image Stabilization Yes

Angle of View (H x V) H: 60.7° ~ 2.33° V: 36.8° ~ 1.38°

Privacy Masking Off / On (5 Areas)

Defog Yes

Encryption Chipset Hardware embedded

Local Storage Micro SD/SDHC/SDXC card slot (1 TB)

Alarm Inputs / Outputs 7 in/2 out

Reset Supported

PTZ

Pan Speed 0.01° ~ 300°/s

Pan Range 360° endless

Tilt Speed 0.01° ~ 300°/s

Tilt Range -10° to 90° Auto flip 180°

Preset Locations 400

Auto Pan Scan Supported

Auto Tracking Supported

Auto Resume After Power Failure Resume to home position

VIDEO

Video Compression H.265 / H.264 / MJPEG, Smart codec

Resolution (16/9) 2592 x 1520/1920 x 1080/1280 x 720

Resolution (4/3) 640 x 480/320 x 240

Number of Video Streams 3

Frame Rate Main/Second Stream/Third Stream/ Fourth Stream

Main Stream: 2592 x 1520/1920 x 1080/1280 x 720 25/30 fps (1920 x 1080 50/60 fps with WDR off)

Second Stream: 1920 x 1080/704 x 576 (PAL)/704 x 480 (NTSC)/640 x 480/352 x 288 (PAL)/352 x 240 (NTSC) 25/30 fps

Third Stream: 640 x 480/352 x 288 (PAL)/352 x 240 (NTSC)/320 x 240 25/30 fps

Bit Rate 100 K~12 Mbps

Analog Output Support CVBS (Reserved)

AUDIO

Audio Compression G.711 a/G.711 Mu

Audio Stream Full duplex

Audio Interface Line in/out

NETWORK

Ethernet 10 Base-T/100 Base-TX Ethernet (RJ-45)

Supported Web Browsers Microsoft Edge, Chrome

Supported OS Microsoft Windows 10, Windows 11

Protocols*

IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS

Interoperability ONVIF Profile G/S/T/M

Maximum Users Access 10 Users

Security

Software: Firmware encrypted&Signed, SD card encryption, User account and password protection, HTTPS, IP Filter, Digest authentication, TLS1.2 only, Stream encryption, AES128/256, SSH/Telnet closed, PCIDSS compliance & attestation

Hardware: Secure boot, Secure authentication chipset built-in

Languages Supported

Arabic, Chinese (Traditional), Czech, Dutch, English, French, German, Italian, Japanese, Korean, Polish, Portuguese (Brazil), Russian, Spanish, Turkish

EVENTS / ANALYTICS

Video Analytics

Standard: Motion detection, Scene change

AI Based: Smart motion, Intrusion, Multi loitering, People counter, Face detection, Line crossing detection, Unattended object detection, Missing object detection

Event Type Analytics alarm, Security alarm, Disk alarm, Recording alarm, Audio detection

Event Linkage Email, Push notification, SD card recording, Digital output

Region of Interest 8

Event

Event notification using digital output

SMTP, FTP, MicroSD card

ELECTRICAL

Power Supply AC24V, PoE++ (IEEE 802.3 bt)(Class 6)

Power Consumption (Max) 45 W

Power Output N/A

MECHANICAL

Dimensions Ø226.10 x 362.80 mm (8.90” x 14.28”)

Product Weight 5.26 kg (11.60 Ib)

Package Weight 7.01 kg (15.45 Ib)

Body Material Metal (die casting aluminum with powder coating)

Color White (RAL9003) + Black

ENVIRONMENTAL

Operating Temperature

Starting Temperature: -40 °C ~ 60 °C (-40 °F ~ 140 °F)

Working Temperature: -40 °C ~ 70 °C (-40 °F ~ 158 °F (IR off)

Relative Humidity Less than 90 %, Non-condensing

Ingress Protection IP66, IP67

Impact Resistance IK10

Heater Supported

Wiper N/A

REGULATORY

Emissions FCC PART 15, CE (EN 55032), ICES-003, Complies with RCM and UKCA

Immunity CE (EN 50130-4, EN 55035), Complies with RCM and UKCA

Safety UL LISTED TO UL/CSA 62368-1, CE (EN 62368-1), Complies with RCM and UKCA

RoHS CE (EN 63000), UAE (cabinet decree No.10 of 2017)
