SYSTEM PARAMETERS

Processor : | 32 Bit High-performance Processor

Storage : | 256M Storage

Operation System : | Linux

Fingerprint Capacity : | Max. 5000 Fingerprints;Up to 10 Local Collected Fingerprint Templates for Each Person

Fingerprint Recognition Duration : | 1 : 1≤1s, 1 : 3000≤1.5s

FAR (False Accept Rate) : | ≤0.001%

FRR (False Rejection Rate) : | ≤0.01%

Fingerprint Recognizer : | Optical Fingerprint Recognizer Module

Card Reading Mode : | Supports EM card reading (DS-K1T201EF/EF-C)

Supports Mifare card reading, including card No. reading, and sector reading & writing (DS-K1T201MF/MF-C)

DEVICE INTERFACES

Accessible Card Reader : | RS485 IC Reader

Input Interface : | Doorbell Button × 1， Door Sensor × 1， Alarm Input × 2， Tamper-Proof Switch × 1， Exit Button × 1

Output Interface : | Doorbell×1, Relay×1

Communication Mode : | TCP/IP, Wi-Fi

Transmission Rate : | TCP/IP, WIFI : 10/100Mbps Self-adaptive,

RS-485 : 19200 bps-N-8-1

USB Interface : | USB2.0

GENERAL

LCD Screen : | 320×240 LCD-TFT Display Screen

Key Board : | 17 Keys

Audio : | 1 Buzzer, 1 Loudspeaker

Power Supply : | 12VDC

Working Current : | ≤500mA

LED Indicator : | Power/ Communication

Working Temperature : | -20°C to +65°C (-4°F to +149°F)

Working Humidity : | 10% to 90% (Non-Condensing)

Dimensions (L×W×H) : | 137mm × 142mm × 35mm (5.4” × 5.6” × 1.4”)

Weight : | 400g (0.88lb)
