Camera

Image Sensor 1/2.8” 2Megapixel progressive scan CMOS

Scanning System Progressive

Effective Pixels 1920(H)x1080(V)

Minimum Illumination 0.02Lux/F2.4 (Color,1/3s,30IRE)

0.08Lux/F2.4 (Color,1/30s,30IRE)

0.01Lux/F2.4 (B/W,1/3s,30IRE)

0.04Lux/F2.4 (B/W,1/30s,30IRE)

IR Distance N/A

IR On/Off Control N/A

IR LEDs N/A

Lens

Lens Type Fixed

Mount Type Board-in

Focal Length 2.8mm

Max. Aperture F2.4

Angle of View H:104° ,V:59°

Optical Zoom N/A

Focus Control Fixed

Close Focus Distance N/A

DORI Distance Detect Observe Recognize Identify

38m(126ft) 15m(50ft) 8m(25ft) 4m(12ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range N/A

Certifications

Certifications CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Environmental

Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection N/A

Vandal Resistance N/A

Construction

Casing Metal

Dimensions Φ30.5mm×48.65mm(Φ1.20”×1.91”)

Net Weight 0.40Kg (0.88lb)

Gross Weight 0.47Kg (1.03lb)
