Thiết bị mạng Router Cisco RV160W-E-K9-G5

Product Model Cisco RV160W

General

Device Type Wireless Security Gateway

Enclosure Type Desktop , Wall-Mount , Plastic

Performance IPSec VPN throughput : 50 Mbps

NAT throughput ( IMIX ) : 600 Mbps

Concurrent sessions : 15000

Capacity Site-to-Site IPSec VPN : 10

Client-to-Site IPSec VPN : 10

Open VPN tunnels : 10

PPTP VPN tunnels : 10

GRE tunnels : 10

Routing Protocol Dynamic Routing ( RIPv1/v2 , RIPng ) , Inter-VLAN Routing , IGMP Proxy , Static Routing

Remote Management Protocol SNMPv1/v2/v3 , HTTP , HTTPS , REST API , NETCONF/RESTCONF

Encryption and Authentication 3DES , AES-128 , AES-192 , AES-256 , SHA1 , SHA2-256 , MD5

Features SPI Firewall , Content Filtering , NAT support , Static NAT , Policy NAT , IPv4/IPv6 access rules , PAT support , DoS attack prevention , Port Mirroring , IPv6 support , VPN passthrough ,   Domain Blocking , 802.1x , LDAP , Active Directory , RADIUS , QoS , DHCP server , Port Forwarding , Port Triggering , DHCP client , PnP deployment , Automatic Updates , Syslog , USB 3G/4G WAN failover

Compliance Standards IEEE 802.11ac , 802.11n , 802.11g , 802.11b , 802.3 , 802.3u , 802.3ab , 802.1D , 802.1p , 802.1X , 802.1Q ( VLAN ) , 802.11i ( Wi-Fi Protected Access [WPA2] security ) , 802.11e ( wireless QoS ) , IPv4 ( RFC 791 ) , IPv6 ( RFC 2460 ) , RIP v1 ( RFC 1058 ) , RIP v2 ( RFC 1723 ) , RIPng , 802.3af , 802.3at

Ports 1 x GE SFP WAN , 1 x RJ-45 GE WAN , 4 x GE  RJ-45 LAN ports , 1 x USB

Interfaces

WAN Interfaces SFP or GE

3G/4G/5G USB Dongle support

LAN Interfaces 4 GE

WiFi 802.11ac ( WiFi-5 )

Antenna External fixed , Non-detachable

Antenna Quantity 2

Anetnna Direction Omni-directional

Antenna Gain 2.4 GHz : 3 dBi

5 GHz : 5 dBi

Power

Power Supply Power adapter - external

Voltage 12V

Electric Current 2A

Miscellaneuos

Width 288 mm ( 11.33in )

Depth 249 mm ( 9.8in )

Height 30 mm ( 1.18in )

Weight 630 g ( 1.39 lb )

Compliance Standards FCC Class A , CE Class B , UL , cUL , CB , CCC , BSMI , KC , Anatel

GUI Language English

Rack Mounting Kit -

Service and Support

Warranty Limited lifetime warranty

Support Included 1 Year Technical Phone Support

Optional Support Services Cisco Smart Net Total Care with advanced hardware replacement

Environmental Parameters

Min Operating Temperature 0°C; 32°F

Max Operating Temperature 40°C ; 104°F

Humidity Range Operating 10% to 85% noncondensing
