Type Cisco Nexus 2232TM-E with 32×1/10GBase-T + 8 x 10GE Module
( includes 16 Fabric Extender Transceivers )
Fabric extender host interfaces
32
Fabric extender host interface type
1/10GBASE-T ports : RJ‑45 connectors
Fabric extender fabric interfaces
Uplink module : 8 x 10 Gigabit Ethernet SFP+ included
Fabric extender fabric interface type
Fiber : Cisco Fabric Extender Transceiver ( FET-10G ) and SFP+ optics ( SFP-10G-SR , SFP-10G-SR-S , SFP-10G-LR , and SFP-10G-LR-S )
Copper : 10 Gigabit Ethernet SFP+ passive Twinax copper cables ( SFP-H10GB-CU1M , SFP-H10GB-CU3M , and SFP-H10GB-CU5M ) and active Twinax copper cables ( SFP-H10GB-ACU7M and SFP-H10GB-ACU10M )
AOC cables :
SFP-10G-AOC1M ,
SFP-10G-AOC2M ,
SFP-10G-AOC3M ,
SFP-10G-AOC5M ,
SFP-10G-AOC7M , and SFP-10G-AOC10M
AOC breakout cables : QSFP-4X10G-AOC1M , QSFP-4X10G-AOC2M , QSFP-4X10G-AOC3M , QSFP-4X10G-AOC5M , QSFP-4X10G-AOC7M , and QSFP-4X10G-AOC10M
Copper breakout cables : QSFP-4SFP10G-CU1M , QSFP-4SFP10G-CU3M , QSFP-4SFP10G-CU5M , QSFP-4x10G-AC7M , and QSFP-4x10G-AC10M
Distance between Cisco Nexus 2000 Series Fabric Extender and Cisco Nexus 5000 or 6000 Series Switch : Up to 10 km
Fabric speed
80 Gbps in each direction ( 160-Gbps full duplex )
Oversubscription
4 : 1
Performance
Hardware forwarding at 800Gbps or 595 mpps
FCoE
FCoE supported up to 30m with Category 6a or 7 cables
Cisco parent switch
Cisco Nexus 5000 Series
Cisco Nexus 6000 Series
Cisco Nexus 7000 Series
Cisco Nexus 9000 Series
Minimum software
Cisco NX-OS Software Release 5.2 ( 1 ) N1 ( 1 ) ( Cisco Nexus 5000 Series )
Cisco Nexus 6000 Series running Cisco NX-OS Software Release 6.0 and later
Cisco NX-OS Release 6.2 ( 2 ) ( Cisco Nexus 7000 Series )
Cisco NX-OS Software Release 6.1 ( Cisco Nexus 9000 Series )
Bộ chia mạng Cisco N2K-C2232TM-E
- Thương hiệu: CISCO
- Mã số sản phẩm: N2K-C2232TM-E
- Tình trạng kho: Liên hệ
-
Xin liên hệ
0 đ
