24-port Gigabit + 4x10G Uplink Switch CISCO C9200L-24T-4X-E

- C9200L-24T-4X-E is the Catalyst 9200L 24-port Data 4x10G uplink Switch, with Network Essentials software.

- Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access.

- Advanced network monitoring using Full Flexible NetFlow.

- Cisco Software-Defined Access (SD-Access)

+ Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisco Identity Services Engine (ISE);

+ Network assurance and improved resolution time through Cisco DNA Center.

- Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network.

- Cisco IOS XE: A Common Licensing based operating system for the enterprise Cisco Catalyst 9000 product family with support for model-driven programmability and streaming telemetry.

- ASIC with programmable pipeline and micro-engine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries.

- Cloud monitoring for Catalyst on Meraki dashboard.

Specifications

Downlinks total 10/100/1000 ports 24 ports data

Uplink configuration 4x 10G fixed uplinks

Fans Fixed redundant

Software Network Essentials

Stacking bandwidth 80Gbps

DRAM 2GB

Flash 4GB

Switching capacity 128Gbps

Forwarding rate 190.4 Mpps

Mean time between failures 525,990 hours

Platform Physical Specifications Chassis Dimensions: 4.4 x 44.5 x 28.8

Chassis + FEP + Fan Dimensions (HxWxD): 4.4 x 44.5 x 32.9

Weight 4.35kg

- Bảo hành: 12 tháng.
