24-port Gigabit Ethernet Data Switch Cisco C9200L-24T-4G-A

- C9200L-24T-4G-A is the Catalyst 9200L 24-port Data 4x1G uplink Switch, with Network Advantage software. Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.

- Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Advantage.

- Downlinks total 10/100/1000 or PoE+ copper ports: 24 ports data.

- Uplink configuration: 4x 1G fixed uplinks.

- Default primary AC power supply: PWR-C5-125WAC.

- Fans: Fixed redundant.

- Software: Network Advantage.

- Stacking bandwidth: 80 Gbps.

- DRAM: 2 GB.

- Flash: 4 GB.

- Switching capacity: 56 Gbps.

- Forwarding rate: 83.33 Mpps.

- Chassis Dimensions: 4.4 x 44.5 x 28.8 cm.

- Weight: 4.35 Kg.

Specification

Model C9200L-24T-4G-A

Downlinks total 10/100/1000 copper ports 24 ports data

Uplink configuration 4x 1G fixed uplinks

Default primary AC power supply PWR-C5-125WAC

Fans Fixed redundant

Software Network Advantage

Chassis Dimensions 4.4 x 44.5 x 28.8 cm

Weight 4.35 kg

Virtual Networks 1

Stacking bandwidth 80 Gbps

Total number of MAC addresses 16,000

Total number of IPv4 routes (ARP plus learned routes) 11,000 (8,000 direct routes and 3,000 indirect routes)

IPv4 routing entries 3,000

IPv6 routing entries 1,500

Multicast routing scale 1,000

QoS scale entries 1,000

ACL scale entries 1,500

Packet buffer per SKU 6 MB buffers for 24- or 48-port Gigabit Ethernet models

Flexible NetFlow (FNF) entries 16,000 flows on 24- and 48-port Gigabit Ethernet models

DRAM 2 GB

Flash 4 GB
