24-Port GE + 4-Port 1G SFP Switch CISCO C1300-24T-4G

- C1300-24T-4G là thiết bị chuyển mạch thuộc dòng Cisco Catalyst 1300 cung cấp 24 cổng 10/100/1000Mbps và 4 cổng 1G SFP uplink. Switch Cisco C1300-24T-4G được tích hợp đầy đủ tính năng layer 3 cùng khả năng quản lý hiệu quả, phù hợp để xây dựng hệ thống mạng tại các doanh nghiệp vừa và nhỏ.

- CPU: ARM dual-core at 1.4GHz.

- DRAM: 1GB DDR4.

- Packet buffer: 1.5MB.

- Tốc độ chuyển tiếp: 41.66Mpps.

- Khả năng chuyển mạch: 56.0Gbps.

Thông số kỹ thuật

Performance

Switching capacity and forwarding rate Capacity in Millions of Packets Per Second (mpps) (64-byte packets): 41.66

Switching capacity in Gigabits per second (Gbps): 56.0

General

Jumbo frames Frame sizes up to 9000 bytes. The default MTU is 2000 bytes

MAC table 16,000 addresses

Chip guard Detects tampering attempts and responds during bootup

Boot integrity Boot integrity visibility allows Cisco's platform identity and software integrity information to be visible and actionable

Hardware

Power consumption (worst case) System power consumption:

+ 110V=14.6W

+ 220V=14.8W

Heat dissipation (BTU/hr): 50.5

Idle Power:

+ 110V=4.9W

+ 220V=5.2W

Ports Total system ports: 28 x Gigabit Ethernet

RJ-45 ports: 24 x Gigabit Ethernet

Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP]): 4 x SFP

Console port Cisco standard RJ-45 console port and USB Type C port

USB port USB Type C port on the front panel of the switch for easy file and image management as well as console port

Buttons Reset button

Cabling type Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T

LEDs System, Link/Act, PoE, Speed

Flash 512 MB

CPU ARM dual-core at 1.4 GHz

DRAM 1 GB DDR4

Packet buffer 1.5 MB
