Chuyển đổi Quang-Điện Media Converter Unmanaged Fiber Switch BTON BT-914GS-20

- Chuyển đổi quang điện Media Converter 10/100/1000 Base-Tx đến 1000 Base-LX, Dual Fiber Single mode.

- Tích hợp 4 cổng Ethernet (RJ45) 10/100/1000Mps.

- Khoảng cách truyền: 20 km.

- Bước sóng quang hoạt động: 1310 nm.

- Ngõ giao tiếp quang: Connector SC.

- Ngõ giao tiếp mạng: RJ45.

- Tương thích các chuẩn: IEEE802.3u, 10/100 Base-TX, 100Base-FX.

- Các đèn LED chỉ thị nguồn, FX LINK/ ACT, 100, TP LINK/ ACT, FDX/ COL.

Features

- Supports 10/100/1000Base-T, 1000Base-X protocol.

- Flow control for full duplex and half duplex.

- Supports up to 10k byte JUMBO frame.

- Supports Fiber Port Trunking, Increasing Fiber Channel Bandwidth and Supply Fiber Channel Redundancy.

- Supports Ports Based VLANS and TAG Based VLANS.

- In conformity to safety code of FCC and CE MARK.

- Connector: 4 RJ-45 connector, one or two fiber connector

- Operation mode: full duplex mode or half duplex mode

- Power supply parameter: DC 5V 1A/2A

- Environmental temperature: 0-50ºC

- Relative humidity: 5%-90%

- UTP cable: Cat5 UTP cable

- Transfer fiber: multimode (50/125, 62.5/125 or 100/140um); single mod (8.3/125,8.7/125, 9/125 or 10/125um).

Specifications

Model BT-914GS-20

Rate 10/100/1000M

Protocol Supported IEEE802.3

Fiber type Dual fiber

Optic mode Single Mode

Ethernet interface RJ-45

Optic interface SC/FC/ST

Optic wavelength 850nm, 1310nm, 1550nm, 1310/1550nm, 1490/1550nm

BER < 1/1000000000

Power 2.5W

Power supply 220VAC/0.5A, 48VDC /0.5A, 5VDC/1A, 2A

Working temperature 0~50ºC

- Sản xuất tại Trung Quốc.

- Bảo hành: 12 tháng.
