Hardware Specifications

CPU CPU Model Realtek RTD1296

CPU Architecture 64-bit

CPU Frequency 4-core 1.4 GHz

Hardware Encryption Engine

Memory System Memory 512 MB DDR4 non-ECC

Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage Drive Bays 2

Compatible Drive Type*

3.5″ SATA HDD

2.5″ SATA HDD ( with optional 2.5″ Disk Holder )

2.5″ SATA SSD ( with optional 2.5″ Disk Holder )

Maximum Internal Raw Capacity 32 TB ( 16 TB drive x 2 ) ( Capacity may vary by RAID types )

Maximum Single Volume Size* 108 TB

Hot Swappable Drive –

Notes

“Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

The maximum single volume size is not directly related to the maximum raw capacity.

External Ports RJ-45 1GbE LAN Port 1

USB 3.0 Port 2

File System Internal Drives

EXT4

External Drives

EXT4

EXT3

FAT

NTFS

HFS+

exFAT*

Notes exFAT Access is purchased separately in Package Center.

Appearance Size ( Height x Width x Depth ) 165 mm x 100 mm x 225.5 mm

Weight 0.88 kg

Others System Fan 92 mm x 92 mm x 1 pcs

Fan Speed Mode

Full-Speed Mode

Cool Mode

Quiet Mode

Low-power Mode

Brightness Adjustable Front LED Indicators

Power Recovery

Noise Level* 18.2 dB ( A )

Scheduled Power On / Off

Wake on LAN / WAN

Power Supply Unit / Adapter 60 W

AC Input Power Voltage 100 V to 240 V AC

Power Frequency 50/60 Hz , Single Phase

Power Consumption* 12.46 W ( Access ) 5.06 W ( HDD Hibernation )

British Thermal Unit 45.52 BTU/hr ( Access ) 17.27 BTU/hr ( HDD Hibernation )

Notes

Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive ( s ) .

Noise Level Testing Environment : Fully loaded with Seagate 2TB ST2000VN000 hard drive ( s ) in the idle state. Two G.R.A.S. Type 40AE microphones , each set up 1 meter away from the Synology NAS at the front and rear. Background noise : 16.49-17.51 dB ( A ) ; Temperature : 24.25-25.75˚C; Humidity : 58.2-61.8%

Temperature Operating Temperature 0°C to 40°C ( 32°F to 104°F )

Storage Temperature -20°C to 60°C ( -5°F to 140°F )

Relative Humidity 5% to 95% RH

Certification

FCC

CE

EAC

BSMI

VCCI

CCC

RCM

KC

Warranty 2 Years

Notes The warranty period starts from the purchase date as stated on your purchase receipt.
